Selecting the measurement mode

Selecting the unit

To select the EMF (EMI) mode, proceed as follows:
1 Push the M
ODE function key.
The Mode menu appears.
EMF (EMI)
2 Select .
The EMF (EMI) main menu appears.
NOTE
This mode is available for selection, if the 9130 EMF Measurement
Option is installed and activated on your instrument.
After selecting the EMF (EMI) measurement mode the next step is to
select the unit.
1 In the main menu, select
2 You can use logarithmic or linear units. In order to toggle the
display between logarithmic and linear units press the
in the lower right corner of the display and select log or lin.
3 You can now choose between the following units via the Unit
softkey in the upper right corner of the display.
Logarithmic units: dBμV/m, dBmV/m and dBV/m
Linear units: V/m, mW/m
9102 Handheld Spectrum Analyzer
Chapter 12 EMF (EMI) Operation
Selecting the measurement mode
Level > Units
.
2
Software version 5.31
Unit
softkey
197
