- Page 1 Digi-Zone Adder Model MDPA2 Ver.04 Installation and Operating Instructions Controlling Your Comfort Room By Room...
- Page 2 Checkout ..…………………………………….…3 Troubleshooting ………………………………...4 The MDPA2 panel case is made of sturdy ABS plastic and can be mounted to any flat surface. It is recommended that the panel be INSTALLATION mounted to a wall or return plenum and NOT on the furnace or plenum where it will be in contact with the hot temperatures..
- Page 3 MDPA2 panel. This cable is connected to the MDPA2 will immediately drop the mode, enter the purge mode in modular plug on the left side of the MDPA2 panel and the other end order to dissipate the conditioned air into the zones calling before connected to the connector on the right side of the MDP3 panel.
- Page 4 Each zone has a LED next to the zone damper plug-in jack, when a another. zone is calling and that call is being recognized by the MDPA2/MDP3 that zone LED will be illuminated GREEN . Provided no other zone is calling for the opposite mode, check the zone that is supposed to be calling and the zone’s LED.
