E2S BExTS110D Instruction Manual page 4

TONE SELECTION TABLE
Tone Selection
Stage 1 Frequency Description
1 Continuous 1000Hz
Toxic gas alarm
2 Alternating 800/1000Hz at 0.25s
intervals
3 Slow Whoop 500/1200Hz at 0.3Hz
with 0.5s gap repeated
4 Sweeping 800/1000 at 1Hz
5 Continuous at 2400Hz
6 Sweeping 2400/2900Hz at 7Hz
7 Sweeping 2400/2900Hz at 1Hz
8 Siren 500/1200/500Hz at 0.3Hz
9 Sawtooth 1200/500Hz at 1Hz
10 Alternating 2400/2900Hz at 2Hz
11 Intermittent 1000Hz at
General alarm
12 Alternating 800/1000Hz at 0.875Hz
13 Intermittent 2400Hz at 1Hz
14 Intermittent 800Hz 0.25s on 1s off
15 Continuous at 800Hz
16 Intermittent 660Hz 150mS on,
150mS off
17 Alternating 544Hz
(100mS)/440Hz(400mS)
18 Intermittent 660Hz 1.8s on, 1.8s off
19 1400Hz to 1600Hz sweep up over
1s - 1600Hz to 1400Hz sweep down
over 0.5s
20 Continuous 660Hz
21 Alternating 554/440Hz at 1Hz
22 Intermittent 554Hz at 0.875Hz
23 800Hz pulsing at 2Hz
24 Sweeping 800/1000Hz at 50Hz
25 Sweeping 2400/2900Hz at 50Hz
26 Simulated bell sound
27 Continuous 554Hz
28 Continuous 440Hz
29 Sweeping 800/1000Hz at 7Hz
30 420Hz repeating 0.625s on, 0.625s
off Australian alert signal
31 1200/500Hz at 1 Hz
Prepare to abandon platform
32 Sweeping 500/1200Hz 3.75s on,
0.25s off 15Hz
__________________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. IS 2427-P Issue B
DIP Switch
Settings
1 2 3 4 5
0 0 0 0 0
1 0 0 0 0
0 1 0 0 0
1 1 0 0 0
0 0 1 0 0
1 0 1 0 0
0 1 1 0 0
1 1 1 0 0
0 0 0 1 0
1 0 0 1 0
0.5Hz 0 1 0 1 0
1 1 0 1 0
0 0 1 1 0
1 0 1 1 0
0 1 1 1 0
1 1 1 1 0
0 0 0 0 1
1 0 0 0 1
0 1 0 0 1
1 1 0 0 1
0 0 1 0 1
1 0 1 0 1
0 1 1 0 1
1 1 1 0 1
0 0 0 1 1
1 0 0 1 1
0 1 0 1 1
1 1 0 1 1
0 0 1 1 1
1 0 1 1 1
0 1 1 1 1
1 1 1 1 1
17-04-02
