Advertisement
Illustrated
Parts List
EXL8000
13500 STARTING WATTS
Models / Modelos
030254
Questions? Help is just a moment away!
Preguntas? La ayuda es justa un momento lejos!
Call: Generator Helpline
Llame: Línea Directa del Generador
1-800-743-4115 M-F 8-5 CT
web: www.briggsandstratton.com
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
Manual No. 200309A
JEFFERSON,WISCONSIN, U.S.A.
Revision - (05/23/2006)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Briggs & Stratton 30254
Summary of Contents for Briggs & Stratton 30254
-
Page 1: Illustrated Parts List
Illustrated Parts List EXL8000 13500 STARTING WATTS Models / Modelos 030254 Questions? Help is just a moment away! Preguntas? La ayuda es justa un momento lejos! Call: Generator Helpline Llame: Línea Directa del Generador 1-800-743-4115 M-F 8-5 CT web: www.briggsandstratton.com BRIGGS &... -
Page 2: Exploded View - Main Unit
EXPLODED VIEW EXPLODED VIEW - MAIN UNIT Copyright © 2006 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power Products Group, LLC. - Page 3 EXPLODED VIEW - PARTS LIST Item Part # Description B194898GS KIT, Cradle 194155GS KIT,Vibration Mount B92531GS BRACKET, Support Engine 190220GS ADAPTER, Engine ASSY, Alternator (see page 5) NUT, Hex M8 - 1.25 B92731GS BRACKET, Support Eng/Muffler 96796GS WASHER WASHER, Lock M8 10 190274BGS SBHC, 3/8-16 x 1"...
- Page 4 EXPLODED VIEW AND PARTS LIST - CONTROL PANEL Item Part # Description 198237GS PANEL, Control 198239GS BOX, Control Panel 192785GS BREAKER, Circuit, 30A 198245GS METER, Hour 75207DGS BREAKER, Circuit, 15A WASHER, Shakeproof, Int. #8 94373GS OUTLET, 120V, 15A Duplex 43437GS OUTLET, 120/240V, 30A WASHER, Flat, M4 10 *...
- Page 5 EXPLODED VIEW AND PARTS LIST - ALTERNATOR EXPLODED VIEW AND PARTS LIST Item Part # Description 186059GS ADAPTER, Mounting, Alternator 194773GS ASSY, Rotor (Includes Item 10) 198498AGS STATOR 193336GS RBC, (with O-Ring p/n 189197GS) 86308KGS HHCS, M6 - 1.0 x 175 SEMS 66386GS ASSY, Holder, Brush 66849GS...
- Page 6 EXPLODED VIEW AND PARTS LIST - WHEEL KIT * - Items without part numbers are common fasteners and are available at your local hardware store. EXPLODED VIEW AND PARTS LIST Item Part # Description 196517GS WHEEL WASHER, 5/8" 191267RGS AXLE, 5/8" 191265GS E-RING HHCS, M8 1.25 x 20...
