  • Page 1 Operator’s Manual Manual del Operario 5800 WATTS Model / Modelo 030205 8800 STARTING WATTS Questions? Help is just a moment away! Preguntas? La ayuda es justa un momento lejos! Call: Generator Helpline Llame: Línea Directa del Generador 1-800-743-4115 M-F 8-5 CT web: www.briggsandstratton.com WARNING ADVERTENCIA...
  • Page 2: Table Of Contents

    SAVE THESE INSTRUCTIONS TABLE OF CONTENTS Safety Rules........2-4 Features and Controls .
  • Page 3: Safety Rules

    WARNING Running generator gives off carbon monoxide, an odorless, colorless, poison gas. Breathing carbon monoxide can cause nausea, fainting or death. • Operate generator ONLY outdoors. • Keep exhaust gas from entering a confined area through windows, doors, ventilation intakes or other openings. •...
  • Page 4 WARNING Running engines produce heat.Temperature of muffler and nearby areas can reach or exceed 150°F (65°C). Severe burns can occur on contact. Exhaust heat/gases can ignite combustibles, structures or damage fuel tank causing a fire. • DO NOT touch hot surfaces and avoid hot exhaust gases. •...
  • Page 5: Features And Controls

    KNOW YOUR GENERATOR Read this operator’s manual and safety rules before operating your generator. Compare the illustrations with your generator, to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference. Recoil Starter Oil Fill Cap Air Cleaner Choke Lever Data Tag...
  • Page 6: Assembly

    ASSEMBLY Your generator requires some assembly and is ready for use after it has been properly serviced with the recommended oil and fuel. If you have any problems with the assembly of your generator, please call the generator helpline at 1-800-743-4115.
  • Page 7: Assembly

    BEFORE STARTING THE ENGINE Engine Oil This engine is shipped from the factory filled with the recommended oil (API SJ or higher SAE 30). Before starting the engine, check oil level and ensure that engine is serviced as described in the engine operator’s manual. CAUTION Any attempt to crank or start the engine before it has been properly filled with the recommended oil will result...
  • Page 8: Using The Generator

    USING THE GENERATOR System Ground The generator has a system ground that connects the generator frame components to the ground terminals on the AC output receptacles.The system ground is connected to the AC neutral wire (the neutral is bonded to the generator frame).
  • Page 9: Starting The Engine

    OPERATING THE GENERATOR Starting the Engine IMPORTANT: Always unplug the battery float charger before starting the generator. Disconnect all electrical loads from the generator. Follow start instruction steps in numerical order: Make sure unit is on a level surface. 2A. For electric starting, follow start instructions given in engine operator’s manual, insert ignition key in ignition switch on generator and turn to “Start”...
  • Page 10: Connecting Electrical Loads

    Connecting Electrical Loads • Let engine stabilize and warm up for a few minutes after starting. • Plug in and turn on the desired 120 and/or 240 Volt AC, single phase, 60 Hz electrical loads. • DO NOT connect 240 Volt loads to the 120 Volt receptacles.
  • Page 11 RECEPTACLES CAUTION Receptacles may be marked with rating value greater than generator output capacity. • NEVER attempt to power a device requiring more amperage than generator or receptacle can supply. • DO NOT overload the generator. See “Don’t Overload Generator”. 120/240 Volt AC, 30 Amp, Locking Receptacle Use a NEMA L14–30 (National Electrical Manufacturers...
  • Page 12: Operation

    DON’T OVERLOAD GENERATOR Capacity You must make sure your generator can supply enough rated (running) and surge (starting) watts for the items you will power at the same time. Follow these simple steps: Select the items you will power at the same time. Total the rated (running) watts of these items.This is the amount of power your generator must produce to keep your items running.
  • Page 13: Maintenance

    SPECIFICATIONS & MAINTENANCE SPECIFICATIONS Starting Wattage ..... 8,800 Watts Wattage ......5,800 Watts AC Load Current At 120 Volts .
  • Page 14: Maintenance And Storage

    Generator Maintenance Generator maintenance consists of keeping the unit clean and dry. Operate and store the unit in a clean dry environment where it will not be exposed to excessive dust, dirt, moisture or any corrosive vapors. Cooling air slots in the generator must not become clogged with snow, leaves or any other foreign material.
  • Page 15: Troubleshooting

    TROUBLESHOOTING Problem No AC output is available, but generator is running. Generator runs good at no-load but "bogs" down" when loads are connected. Generator will not start; or starts and runs rough. Generator shuts down during operation. Generator lacks power. TROUBLESHOOTING Cause One of the circuit breakers is...
  • Page 16: Notes

    NOTES NOTES...
  • Page 17: Warranty

    Effective February 1, 2006 replaces all undated Warranties and all Warranties dated before February 1, 2006 Briggs & Stratton Power Products Group, LLC will repair or replace, free of charge, any part(s) of the portable generator that is defective in material or workmanship or both. Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser.
  • Page 18: Conserve Estas Instrucciones

    CONSERVE ESTAS INSTRUCCIONES TABLA DE CONTENIDOS Reglas De Seguridad ....... . 18-20 Características y Controles .
  • Page 19: Reglas De Seguridad

    ADVERTENCIA Al generador funcionar, se produce monóxido de carbono, un gas inodoro y venenoso. El respirar el monóxido de carbono, producirá náusea, desmayo o la muerte. • Opere el generador SOLAMENTE al aire libre. • Asegúrese de que los gases de escape no puedan entrar por ventanas, puertas, tomas de aire de ventilación u otras aberturas en un espacio cerrado en el que puedan acumularse.
  • Page 20 ADVERTENCIA Los motores al funcionar producen calor. La temperatura del silenciador y de las áreas cercanas puede alcanzar o pasar los 150ºF (65ºC). Quemaduras severas pueden ocurrir al hacer contacto. Los gases y el calor de escape pueden inflamar los materiales combustibles y las estructuras o dañar el depósito de combustible y provocar un incendio.
  • Page 21: Características Y Controles

    CONOZCA SU GENERADOR Lea este manual del operario y las reglas de seguridad antes de operar su generador. Compare las ilustraciones con su Generador para familiarizarse con las ubicaciones de los diferentes controles y ajustes. Conserve este manual para referencias futuras. Culatazo el Principio Aceite Llena la Tapa Depurador de Aire...
  • Page 22: Desembalaje Del Generador

    MONTAJE Su generador requiere de ciertos procedimientos de montaje y solo estará listo para ser utilizado después de haberle suministrado servicio con el combustible y aceite recomendados. Si usted tiene problemas con el montaje de su generador, por favor llame a la línea de ayuda para generadores al 1-800-743-4115.
  • Page 23: Agregue Combustible

    ANTES DE DARLE ARRANQUE AL MOTOR Aceite de Motor Este motor se envía desde la fábrica lleno con el aceite recomendado (API SJ o más alto SAE 30).Antes de arrancar el motor, verifique el nivel de aceite y asegúrese de que el motor haya recibido el mantenimiento que se describe en la manual del motor.
  • Page 24: Tierra Del Sistema

    USO DEL GENERADOR Tierra del Sistema El generador dispone de una conexión a tierra del sistema que conecta los componentes del bastidor a los terminales de tierra de los enchufes hembra de salida de CA. La tierra del sistema está conectada al cable de CA neutro que, a su vez, está...
  • Page 25: Encienda El Motor

    OPERANDO EL GENERADOR Encienda el Motor IMPORTANTE: Siempre desconecte el cargador de flotante de la batería antes de arrancar el generador. Desconecte todas las cargas eléctricas del generador. Use las siguientes instrucciones para encender, paso por paso, en orden numérico. Asegúrese de que la unidad está...
  • Page 26: Parado Del Motor

    Conexion De Cargas Electricas • Deje que el motor se estabilice y se caliente por unos minutos después del arranque. • Conecte y encienda las cargas eléctricas de 120 y/o 240 Voltios AC monofásicas de 60 Hz que desse. • NO conecte cargas de 240 Voltios a tomacorrientes de 120 Voltios.
  • Page 27 RECEPTÁCULOS PRECAUCIÓN El valor nominal que se indica en los enchufes hembra puede ser superior a la capacidad de salida del generador. • NUNCA intente suministrar corriente a un dispositivo de amperaje superior al que puede suministrar el generador o el enchufe hembra. •...
  • Page 28 NO SOBRECARGUE GENERADOR Capacidad Usted debe asegurarse que su generador puede proveer el suficiente vataje calificado (cuando esté funcionando) y de carga (al encender) para los aparatos a los cuales va a proveer la energía, al mismo tiempo. Siga estos pasos: Seleccione los aparatos que recibirán la energía, al mismo tiempo.
  • Page 29: Recomendaciones Generales

    ESPECIFICACIONES Y MANTENIMIENTO ESPECIFICACIONES Vataje que empieza....8,800 Vatios (8.8 kW) Vataje ......5,800 Vatios (5.8 kW) Corriente valorada de Carga de C.A.: a 240 Voltios.
  • Page 30: Mantenimiento Del Generador

    MANTENIMIENTO Y ALMACENAMIENTO Mantenimiento del Generador El mantenimiento del generador consiste en conservar la unidad limpia y seca. Opere y almacene la unidad en un ambiente limpio y seco donde no será expuesta al polvo, suciedad, humedad o vapores corrosivos. Las ranuras del aire de enfriamiento del generador no deben estar tapadas con nieve, hojas, o cualquier otro material extraños.
  • Page 31: Diagnosticos De Averías

    DIAGNOSITICOS DE AVERÍAS Problemo El motor está funcionando pero no existe salida de AC disponsible. El motor funciona bien sin carga pero "funciona mal" cuando se le contectan cargas. El motor no se enciende; o se enciende y funciona mal. El motor se apaga en pleno funcionamiento.
  • Page 32: Garantia

    POLÍTICA DE GARANTÍA PARA EL PROPIETARIO DE GENERADOR PORTÁTIL BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC Fecha de entrada en vigor:1 de Febrero de 2006. Sustituye a todas las garantías sin fecha y a las de fecha anterior al 1 Febrero de 2006 Briggs &...
