conductive items to avoid any possible damages. And also please do not pull or
bend the pins;
7. Please pay attention to the pressure measurement range, and don't act large
pressure over FS for a long time. If the pressure exceeds the overpressure, the
sensor may be destroyed;
8. When assembling the sensor, please apply a little vacuum grease around the
"O" ring. If the media is oxygen, please do not apply any lubrication;
9. During application, please note the high and low sides of the differential
sensor. They are marked "H" and "L" on the body separately. Make sure the
pressure on the high side should be higher than that of the low side.
10. We recommend you operate differential pressure sensor with 3-manifold
valve together.
11. Please be sure the wet and corrosive media shall not go into the electric
connection part. Please keep the breath tube (only Gauge Type sensor) connect
with atmosphere
12. For pin electric connection, the sensor pins could be cut off, but the
remaining length shall be ≥ 5mm and welding time shall be ≤ 5s. The pins
could not be heated for a long time.
Definition
NL：Non-linearity
RP：Repeatability
HY：Hysteresis
SPAN：FS Output
TCZ：Zero Temp. Coefficient
TCSP：FS Temp. Coefficient
