11 -IN
12 +IN
Note: The actual electric connection method, please check the parameter label enclosed with
products.

Attentions

1. Please be sure the pressure sensor' construction material is compatible with
measuring media.
2. please pay attention to the normal usage conditions of this product:
Power Supply: ≤2.0mADC or ≤10VDC.
Working Temp/ Storage Temp Range: -40℃ ~ 125℃.
3. The pressure sensor should be mounted as SUSPEMSION mode according to
the suggested installation dimension. Please pressurize it slowly and be sure the
measured pressure should not exceed the overpressure of the sensor; Normally, the
measured pressure should be within the pressure measurement range;
4. Please be sure it is static-free for ground equipment and personnel when
assembling and operating. The electrical contact pads are protected against ESD up
to 4 kV HBM (human body model).
5. Please do not press the diaphragm with sharp things or figures. When
assembling the sensor, please clean up the scrap iron and other remains in the
installation hole to avoid any damages on the sealing ring and diaphragm;
6. Please do not press the compensated board and do not contact it with any
White
Black
The rest pins are useless.
