Summary of Contents for Omnisense Systems Ulysses micro
- Page 1 High performance compact thermal camera Part No: ULS-M384U, ULS-M384S, ULS-M640S User Manual Ver 3.1...
-
Page 3: Table Of Contents
04 - Operations ......................17 4.1 Powering-up ..........................17 4.2 Login to camera........................... 17 4.3 Gyro calibration (Ulysses Micro S and S+ only) ..............18 4.4 Thermal display image ......................19 4.5 Operating the camera ......................20 4.6 Camera control ..........................22 05 - Menu ........................23... - Page 4 5.5 Settings ............................29 5.5.1 Information ........................29 5.5.2 Device Access ........................30 5.5.3 Network Setup ......................... 31 5.5.4 Video ..........................32 5.5.5 Position ..........................33 5.5.6 Function ..........................36 5.5.7 Controller ........................... 38 5.5.8 Junction Box ........................40 5.5.9 NMEA ..........................41 5.6 Home/Standby ..........................
-
Page 5: Important Information
This product is intended for use on marine vessels not covered by the International Maritime Organization (IMO) and Safety of Life at Sea (SOLAS) Carriage Regulations. Using the supplied cables as is Do not cut or extend all Omnisense Systems supplied cables unless doing so is detailed in the installation manual. -
Page 6: Notices
Omnisense Systems will not be held liable for any damages resulting from the use of this product. While every effort has been made to ensure that the information in these manuals is accurate and complete, we would appreciate it were you to bring any errors or omissions to the attention of the Omnisense Systems representative in your area. -
Page 7: Introduction
02 - Introduction Thank you for choosing the Ulysses Micro marine thermal camera. The Ulysses Micro comes with all the components ready to install and operate making it the most user-friendly marine thermal camera system available. The camera system is designed to integrate with many popular Multi-function Displays (MFDs), please check on our website support page for the latest supported brands and models. -
Page 8: Optional Accessories
2.3 Optional accessories The Joystick Controller, Riser and a longer Camera Harness (100ft / 30m) can be purchased separately to be incorporated into a new or existing system as per your requirements. Joystick Controller Riser Camera Harness (100ft / 30m) 2.4 Installation tools requirements The following are additional tools and items required for installation that are not included in the package. -
Page 9: Getting To Know The Camera
2.5 Getting to know the camera Take a few moments to familiarize yourself with camera controls and displays. You may find it helpful to bookmark this section and refer to it as you read through the rest of the manual. Camera Turret Camera (tilt +100˚... -
Page 10: Installation & Setup
The diagram should include the location of all components, cable types, routing and length. This is the layout plan of how your Ulysses Micro thermal camera system will be set-up. 1. Camera Turret 2. - Page 11 • Omnisense Systems products conform to the appropriate Electromagnetic Compatibility (EMC) regulations. To minimize electromagnetic interference between equipment, we recommend that wherever possible, Ulysses Micro equipment and cables connected to it are: • at least 3ft (1m) from any equipment transmitting or cables carrying radio signals. e.g.
-
Page 12: Mounting The Camera Turret
3.3 Mounting the Camera Turret The Camera Turret holds the imaging module, optics and Pan/Tilt platform. The Camera Turret can be configured to be installed ball-up (upright) or ball-down (upside-down) position. Identify and select a position with a clear line of sight to the intended observation area. The mounting area should also be secure and free from excessive vibration. -
Page 13: Installing The Junction Box
Screws Detachable Cover Housing Base 3.4 Installing the Junction Box The Junction Box is the main interface that handles communication between the components. It also distributes the power supply to the Camera Turret and the Joystick Controller. The Junction Box consists of the housing base, a see-through polycarbonate cover and it is secured by two M5 studs on each side of the box. - Page 14 Black for (-) negative, White for (+) positive 6. NMEA 0183 socket - Your Ulysses Micro system may have functions that require input from NMEA 0183 devices. To utilize those functions, connect your NMEA 0183 data source to the [NMEA] socket in the Junction Box using 24-20 AWG cables.
-
Page 15: The Joystick Controller (If Purchased)
3.5 The Joystick Controller (if purchased) The Joystick Controller is the physical controller for the camera system. The Joystick Controller is meant to be panel mounted. If correctly installed, the top side of the Joystick Controller is waterproof and suitable for open deck installation. Identify and select an installation position that provides the best ergonomics for controller operation. -
Page 16: Connecting To Your Display Options
2. The default settings in the User Interface (UI) is for Garmin MFD. If you are using a Garmin’s MFD, you should see a Ulysses Micro icon on the display after powering up both the MFD and camera system. Launch the Ulysses Micro icon to access the UI. -
Page 17: Connecting To An Analog Monitor
3.6.2 Connecting to an analog monitor 1. Connect the AV analog cable from the [AV] port in the Junction Box to your analog monitor. 2. The display will appear on the screen. Use the Joystick Controller to control the camera. 3. -
Page 18: Connecting To A Laptop/Desktop
3.6.3 Connecting to a laptop/desktop 1. Connect an ethernet cable (not provided) from the [Controller/MFD] in the Junction Box to your computer. 2. On your web browser, enter the default IP address (172.16.6.225) indicated at the base of the Camera Turret and use the following login credentials to set up the camera. Username: admin Password: 12345 3. -
Page 19: Operations
04 - Operations 4.1 Powering-up The Ulysses Micro system automatically powers up when it is connected to your vessel’s power. 1. Ensure that you have connected the Camera Harness to the Camera Turret. 2. Ensure that your video output is connected and your display is powered on. -
Page 20: Gyro Calibration (Ulysses Micro S And S+ Only)
4.3 Gyro calibration (Ulysses Micro S and S+ only) Upon powering up/waking up from Standby mode, the system will initiate a gyro calibration sequence. A “gyro calibrating” message will be displayed on the screen when calibration is performed. • If gyro-calibration is successful, a “Gyro calibration successful” message will be displayed. -
Page 21: Thermal Display Image
4.4 Thermal display image Upon successful login, a thermal display image will appear on the screen. The camera outputs an IP-video feed that can be displayed on a compatible Multi-function display (MFD), an analog monitor, or a desktop/laptop via a web browser. Take some time to familiarize yourself with the thermal image on your display. -
Page 22: Operating The Camera
Install the Joystick Controller to access the camera (see section 5.5.7) The Quick Menu and the Virtual Joystick will disappear after 3 seconds of inactivity. Zoom Indicator Sensor Select* Quick Menu Menu Function Direction Indicator Virtual Joystick *Sensor Select function is not available for Ulysses Micro... - Page 23 NUC). See section 5.5.6 to learn how to program the shortcut key. Menu Menu access to the camera system functions and settings. Sensor Select Toggle between thermal and day cameras. This feature is not available in the Ulysses Micro system.
-
Page 24: Camera Control
4.6 Camera control The Virtual Joystick and/or the knob on the Joystick Controller (if purchased) controls all panning and tilting operations of your Turret and Camera. Use the Virtual Joystick or Joystick Controller to pan (turn left or right) and tilt (up or down) the camera to search and acquire a visual on your target. -
Page 25: Menu
05 - Menu Select to access the functions and settings of the camera. The list of menu icons will appear on the right of the screen. Select a menu icon on the display or Joystick Controller to access the respective function listed on the table below. Select from 6 different color palettes Color Palette See section 5.1 for more details... -
Page 26: Color Palette
5.1 Color Palette Select to access the Color Palette. Select your preferred color scheme from the 6 different color modes available. Tap or click anywhere on the screen to exit the menu. If using the Joystick Controller, select by moving the knob up or down. Colour Feature White Hot... -
Page 27: Zoom
5.2 Zoom The Ulysses Micro features a fix-focus imaging sensor with the ability to zoom into target objects up to 4.0X magnification. • Select to activate the zoom slider. • Move the slider to the left or right to control the amount of magnification. -
Page 28: Brightness & Contrast
5.3 Brightness & Contrast 1. Select to activate the function. 2. Move the Brightness slider to the left or right to control the amount of brightness. 3. Move the Contrast slider to the left or right to control the amount of image contrast. 4. -
Page 29: Radar Track
Stabilization mode is now active. 5.4.2. Heading Lock (Ulysses Micro S and S+ only) Heading Lock mode provides tilt (up and down) stabilization for enhancing image stability as the vessel moves and turns. Unlike full stabilization mode, the camera is not locked onto a fixed point. -
Page 30: Radar Tracking (Slew-To-Cue)
• The camera will slew to the selected direction and the target will be shown on the display if the target is within the performance range of the camera. The Stabilization & Headling Lock modes are only applicable on the Ulysses Micro S and Ulysses Micro S+ version. -
Page 31: Settings
7. Controller 8. Junction Box 9. NMEA 5.5.1 Information The Information section provides an overview of the camera system configuration. Camera S/N : Ulysses Micro 0000001 Orientation : Ball Up Camera IP : 10.10.100.125 Frame Rate : Junction Box :... -
Page 32: Device Access
5.5.2 Device Access In this section, you can change the default password and IP address for the camera system. Password : 10 . 10 . 100 . 125 IP Address : Furuno Garmin Navico Network Setup Save & Reboot How to change the password 1. -
Page 33: Network Setup
5.5.3 Network Setup In this section, you can manually configure the IP address, subnet mask and gateway for your camera unit. Change the settings accordingly if they cause IP address conflict with other devices in your network. To change the IP address settings: 1. -
Page 34: Video
5.5.4 Video In the Video section, you can change the Frame Rate (fps) and/or the Video Output Format. Frame Rate : Video Output : NTSC Bitrate: Save & Reboot Frame Rate There are three different video frame rates options: 3, 6 or 9. Selecting on any of the option will activate it immediately. -
Page 35: Position
5.5.5 Position In this section, you can change the Camera Orientation and set the Home Position. Camera Orientation : Ball Down Ball Up Set Home Position : Reset Home Position : Save & Reboot Camera Orientation Depending on how you have mounted your camera, you will need to select either [Ball up] with the Camera unit mounted “upright”... - Page 36 Set Home Position The system has a function that allows you to preset your preferred offset pan and tilt position of the camera when the [Home] option is activated. To utilize this function: 1. At the Set Home Position field, select [Set]. 2.
- Page 37 Reset Home Position The [Reset Home Position] function resets the offset “Home” position back to the original factory settings. To reset the “Home” position to factory default: 1. At the Reset Home Position field, select [Set] once. 2. Select [OK] on the dialog box to confirm. 3.
-
Page 38: Function
The system is compatible with Furuno, Garmin or Navico’s MFD. The [MFD Support] is switched on by default. When you switched on the MFD and Ulysses Micro system, the MFD will automatically detect the camera and display the Ulysses Micro icon on the screen. You can launch the Ulysses Micro user interface (UI) by tapping/clicking on the icon. - Page 39 The camera is pre-installed with variable color LED lightings. Select the preferred color from the seven color preset. For customization of the lighting’s color, select the last color icon and adjust the slider for [Red], [Green] and [Blue] accordingly. To change the brightness of the LED, simply shift the slider for [LED Brightness]. LED Color: Custom Color : LED Brightness :...
-
Page 40: Controller
5.5.7 Controller In this section, you can connect to the Joystick Controller(s), set the IP address and adjust the CONTROLLER Scan Controller Serial No. : ULS-OMS-CR-091905 IP Address : 10 . 225 . 225 LED Color : Custom Color : LED Brightness : background lightings of the Joystick Controller(s). - Page 41 CONTROLLER Back Controller Serial No. ULS-OMS-CR-091905 Joystick Controller’s serial number Select this to connect to the Joystick Controller See the next page for section image. Connecting additional Joystick Controller(s) The system is designed to connect to additional Joystick Controller(s). To connect additional Joystick Controller(s) to the camera system network, simply repeat the steps mentioned above.
-
Page 42: Junction Box
5.5.8 Junction Box In this section, you can view the Junction Box serial number and IP address. You can change the Junction Box’s IP address and set the NMEA baud rate. CONTROLLER JUNCTION BOX NMEA Junction Box Serial No. : 00190046 IP Address : 10 . -
Page 43: Nmea
5.5.9 NMEA This function allows the camera system to be connected to the NMEA equipment through NMEA 2000 (Ethernet connection). This allows you to activate the Slew-to-Cue capability of the camera system. To activate the function, slide to the right. CONTROLLER JUNCTION BOX NMEA... -
Page 44: Home/Standby
5.6 Home/Standby The [Home/Standby] function allows you to wake, park, or return the turret to home position. • Select [Home] will set the turret back to the preset home position. • Select [Standby] will park the turret. The lens will be stored either to face down (ball-up) or face up (ball-down). -
Page 45: Joystick Controller
06 - Joystick Controller Display controls are provided by the 8 buttons on the Joystick Controller and the Virtual Controller on the web browser. Press the button once to access the menu items. Use the joystick to select and cycle-through the options available. - Page 46 Use the joystick to control the amount of zoom See section 5.2 for more details Toggle between thermal and day cameras Sensor Select Not available for Ulysses Micro Home/Standby See section 5.6 for more details Radar Tracking or Slew-to-Cue Track See section 5.4 for more details...
-
Page 47: Maintenance
• exposed to temperatures above 85°C or below -40°C 7.3 Service and maintenance This product contains no user-serviceable components. With the exception of regular cleaning, please refer all maintenance and repair to Omnisense Systems. Unauthorized repair will void the manufacturer’s warranty. -
Page 48: Troubleshooting
08 - Troubleshooting If the camera fails to function as expected, check the list of common problems below before consulting your retailer or Omnisense Systems representative. Problem/Error Possible causes Possible solution Indications Junction Box No power to the Check that the power is switched on... - Page 49 Cannot pan/tilt Dirt build-up Check the space between the turret and the mounting base for any build-up of deposits. Gently flush the turret and the mounting base with fresh water to dislodge the accumulation of minerals from salt water and sea spray. No response Improper connection Check that the cables are connected properly...
-
Page 50: Specifications
09 - Specifications General Micro Micro S Micro S+ Thermal Resolution 384 X 288 384 X 288 640 X 480 Field of View 29° (H) X 22° (V) 24° (H) X 18° (V) 24° (H) X 18° (V) Stabilization Focal Length 13mm Sensor Type 17um Uncooled Microbolometer LWIR FPA... - Page 52 Omnisense Systems USA Inc 1881 West State Road 84, Bldg. 1 Unit 102 Fort Lauderdale, Florida, 33315, United States T: +1 (954) 316-6230 E: enquiries@omnisense-systems.com omnisense-systems.com...
