- Page 1 AMPLIFIERS FOR MAST...
- Page 2 AMPLIFIER FOR MAST CODE 9030185 9030186 MODEL AM-183 AM-187 Number of inputs Frequency range Band BIII/DAB BIII/DAB 88-108 160-260 470-694 88-108 160-260 470-694 Gain Adjustable gain range Output level DIN 45004B dBµV (IMD -66 dB) (IMD -60 dB) Noise gure ±1,0...
- Page 3 HOW TO INSTALL AND FIX THE AMPLIFIER AMPLIFIER Gain regulator Power indicator 32dB Made in Spain 2 IN BIII/FM 20dB 1 IN 1IN-Not used 1IN-UHF/BIII/FM 2IN-BIII/FM 2IN-UHF +12V +12V Inputs switch Inputs Output and power supply...
- Page 4 HOW TO CHANGE THE INPUTS Combination UHF / BIII 32dB Position 1 IN Made in Spain 2 IN BIII/FM Using a VHF/UHF combination TV 20dB 1 IN 1IN-Not used 1IN-UHF/BIII/FM antenna, single input 2IN-BIII/FM 2IN-UHF +12V +12V BIII/FM 32dB Made in Spain Position 2 IN 2 IN BIII/FM...
-
Page 5: Connection To Power Supply
CONNECTION TO POWER SUPPLY Indicator light should be “ON” for correct operation 32dB Made in Spain 2 IN BIII/FM 1 IN 20dB 1IN-Not used 1IN-UHF/BIII/FM 2IN-BIII/FM 2IN-UHF +12V +12V Output and power supply Power injector To ampli er To TV 240 V Mains plug pack Output 12 V... -
Page 6: Declaration Of Conformity
ALCAD, S.L. Company Address: Pol. Ind. Arreche-Ugalde, 1 Apdo. 455, 20305 IRÚN (Guipúzcoa), SPAIN declares that the product Model Number(s): AM-183, AM-187 MAST BROADBAND AMPLIFIERS and POWER SUPPLIES Product Description: Product Option(s): INCLUDING ALL OPTIONS is in conformity with: Safety:...
