MONTAGEVARIANTEN

DE
EN
FR
NL

VERSTELLBEREICH

Auftrag Nr.:
Sondergrößen • special sizes • mesures spéciales • speciale maten
B= cm

ASSEMBLY VARIATIONS

Montage ohne Duschwanne.
Assembly without shower tray.
Montage sans receveur de douche.
Montage zonder douchebak.
B

ADJUSTMENT RANGE

C=

VARIANTES DE MONTAGE

POSITIONNEMENT

Serie
80
cm
90
100
120
8 / 30
Artweger
DYNAMIC

MONTAGEVARIANTEN

C

VERSTELBAARHEID

B C
77,4cm ± 1cm 77,4cm ± 1cm
87,4cm ± 1cm 87,4cm ± 1cm
97,4cm ± 1cm 97,4cm ± 1cm
117,4cm ± 1cm ---
