- Page 1 SELF-PRIMING ELECTRIC PUMP FOR TRANSFERRING VARIOUS LIQUIDS INSTRUCTIONS FOR USE 164 936 15-US - OCK8-E 12/24V © S.p.A.
- Page 2 FEATURES · The circuit lights up: The green and red LEDs slowly flash, while the circuit is performing the initial self-check and parameter reset. If something fails, the pump does not come out of this condition and the red and green LEDs continue to blink indefinitely. ·...
- Page 3 · If the “ON/OFF” button is held pushed at power-on until the green led flashes, the automatic start of the pump is toggled (i.e. if the pump starts immediately after power on or if it waits an user input before starting). ·...
- Page 4 REPORTING ERRORS · If the control circuit is forced to lower the motor speed due to the power limiter, when it reaches a threshold considered as "abnormal operation", the red LED will start to blinking quickly and after 5 seconds the pump will stop. ·...
- Page 5 PRODUCT DESCRIPTION Self-priming electric pump for the transfer of liquids of varied nature. The pumping elements are made up of bronze gears which can possibly even run dry for brief periods. TECHNICAL DETAILS Tab.1 EN FUSE FLOW RATE (*) PRESSURE WEIGHT WIRE SIZE (**) CODE...
-
Page 6: Ambient Conditions
AMBIENT CONDITIONS TEMPERATURE: min.-10°C 14°F-max.60°C 140°F RELATIVE HUMIDITY: max. 90 % WARNING: the above indicated temperature ranges are applicable to all components of the pump and these limits must be respected in order to avoid any possible damage or malfunctioning. OPERATING CYCLE Under conditions of high operating pressures the pump can be subjected to elevated stresses and overheating and therefore should not be used for prolonged periods under such... - Page 7 To ensure the correct directional flow of the fluid as indicated by the arrow on the top plate, it is necessary to connect the positive pole (+) of the battery supply to the red wire on the motor end-cap and the negative pole (-) to the black wire. Electrical connections must be made using adequate terminal blocks and connectors ensuring a tight fitment of the electrical cables.
-
Page 8: Troubleshooting
TROUBLESHOOTING CHECK POINTS IF THE PUMP HAS STOPPED OR WILL NOT START Ø Check the effectiveness of the battery power supply (voltage activity); Ø Check if the fuse has blown; Ø Check for any foreign matter present in the pump body. To do this, disconnect the power supply and unscrew the four fixing screws, remove the front cover plate and inspect the chamber. -
Page 9: Warranty
5) The Warranty does not cover any related installation costs involved. 6) Transport costs are refundable only in the case where warranty has been duly accepted by Marco Spa and they will be limited to the actual shipment costs between Marco Spa warehouse and the client's delivery address. - Page 10 EXPLODED VIEW © S.p.A.
- Page 11 DIMENSIONS © S.p.A.
- Page 12 DIAGRAMS FLOW RATE DIAGRAM 14,5 29,0 43,5 58,0 72,5 AMPERE-DRAW DIAGRAM 14,5 29,0 43,5 58,0 72,5 © S.p.A.
- Page 13 WARNING HOT SURFACE © S.p.A.
- Page 15 E.C. DECLARATION OF CONFORMITY We confirm that the product: 164 936 15-US - OCK8-E 12/24V Electronic Gear pump is in conformity with the Directive 2014/30/EU (ex. 2004/108/EC) relating to electromagnetic compatibility and with the Directive 2006/42/EC relating to the machines.
- Page 16 Property of MARCO S.p.A reproduction prohibited. All rights reserved. For further information visit our web site - www.marco.it Marco S.p.A Via Mameli 10 - 25014 Castenedolo (Brescia) – Italy tel. +39 030 2134.1 / Fax +39 030 2134.300...
