Supplement
Zeus Infinity Empowered
WARNING
To properly use this medical device,
read and comply with the instructions
for use and this supplement.
Anesthesia workstation system
Software 2.n

Advertisement

loading
Need help?

Need help?

Do you have a question about the Zeus Infinity Empowered and is the answer not in the manual?

Questions and answers

Related Manuals for Dräger Zeus Infinity Empowered

Summary of Contents for Dräger Zeus Infinity Empowered

  • Page 1 Supplement Zeus Infinity Empowered Anesthesia workstation system WARNING To properly use this medical device, Software 2.n read and comply with the instructions for use and this supplement.

  • Page 2: Information About This Document

    English English Supplement Zeus Infinity Empowered en Supplement to the instructions for use Instructions for use Part number Edition Zeus IE SW 2.n 9054908 1 – 2015-02 and higher  Keep this supplement with the instructions for NOTE use. The names of the chapters in the referenced doc- uments may differ.

  • Page 3: Safety Information

    30 minutes. – Before inserting the flow sensor check for visible damage and soiling, such as resid- ual mucus, medication aerosols, and parti- cles. – Replace flow sensors when damaged, soiled, or not particlefree. Supplement Zeus Infinity Empowered...
  • Page 4 Do not reuse, reprocess, or sterilize dispos- able products. Information on reprocessing Follow the national infection prevention policies and reprocessing regulations. Follow the infection prevention policies and reprocessing regulations of the health-care facility (e.g., concerning the reprocessing cycles). Supplement Zeus Infinity Empowered...
  • Page 5 – Housing (upper part and lower part) – Expiratory port, inspiratory port – APL valve – Additional air valve – Flexible breathing bag arm (option) – TurboVent 2 blower module – Absorber container and absorber insert Supplement Zeus Infinity Empowered...
  • Page 6 Removing patient-specific accessories and piece, inspiratory port, or expiratory port. consumables Remove the following accessories: Removing the breathing bag – Breathing hoses Remove the breathing bag and hose (B). – Breathing bag – Filters – Water traps Supplement Zeus Infinity Empowered...
  • Page 7 Removing the sample lines line, these residues can get into the water trap and the patient-gas measurement module lat- er. This may result in faulty measurements. Sample lines are disposable products. Dis- posable products must not be disinfected. Supplement Zeus Infinity Empowered...
  • Page 8 – Protect: Water trap for the internal sample line – CO : Water trap for the patient sample line 1 Pull off the CO2 water trap (E) towards the front. 2 Pull off the Protect water trap (F) towards the front. Supplement Zeus Infinity Empowered...
  • Page 9 4 Remove the absorber insert (C) from the absorber container. The sealing ring (D) 3 Flip the holder back until it clicks into place. remains on the absorber insert. 5 Prepare the CO absorber for cleaning and disinfection in the washer-disinfector. Supplement Zeus Infinity Empowered...
  • Page 10 2 Loosen the knurled nut on the inspiratory port sorber. (B). Remove the port. Removing the CLIC adapter (optional) C (2x)  Follow the instructions for use for the CLIC adapter. 3 Remove the two flow sensors (C). Supplement Zeus Infinity Empowered...
  • Page 11 3 Unscrew the additional air valve (C). 4 Prepare the housing parts for cleaning and disinfection in the washer-disinfector. 1 Loosen the knurled screws (A) on the connector on the arm. 2 Pull the arm off the breathing system. Supplement Zeus Infinity Empowered...
  • Page 12 90° counterclockwise. receiving system on the back of Zeus IE. 2 Remove the blower module (B) from the 2 Remove the transfer hose (B). breathing system mount (C). 3 Remove the anesthetic gas receiving system (C). Supplement Zeus Infinity Empowered...
  • Page 13 – Additional air valve – Flexible breathing See pages 17 and 17 bag arm (optional) – TurboVent 2 blower See pages 17 and 18 module – Absorber container See pages 17 and 18 and absorber insert Supplement Zeus Infinity Empowered...
  • Page 14 Cleaning 1 Wipe off obvious soiling using a disposable cloth (or a similar cloth) soaked in surface disinfectant and dispose of this. 2 Wipe all surfaces. After that, there must no longer be any soiling visible. Supplement Zeus Infinity Empowered...
  • Page 15 – The breathing system has been removed. WARNING Risk due to penetrating liquid Penetrating liquid may cause the following: – Damage to the device – Electric shock – Device malfunctions Ensure that no liquid penetrates the device. Supplement Zeus Infinity Empowered...
  • Page 16 – – – Min. 90 °C Min. 5 min (194 °F) Drying – – – – Drying time de- pends on the load Prerequisites: – The washer-disinfector has been prepared in accordance with the manufacturer's instructions. Supplement Zeus Infinity Empowered...
  • Page 17 2 Place both of them in the load carrier. 3 Connect the other end of the hose to a suitable nozzle (C) on the load carrier.  Position the breathing system (A) and the housing cover (B) slightly tilted. Supplement Zeus Infinity Empowered...
  • Page 18 Absorber container 1 Fit the TurboVent 2 blower module (A) in the holder (B). Make sure the lock snaps audibly into place.  Place the absorber container with the opening facing downwards on an injector nozzle. Supplement Zeus Infinity Empowered...
  • Page 19 2 When the cycle has ended, check the components for visible soiling and repeat the cycle if necessary. 3 Check the components for visible damage and replace if necessary. 5 If necessary, fix the cap (C) on the holder (E) Supplement Zeus Infinity Empowered...

  • Page 20: Storage And Transport

    Surface disinfectant The manufacturers of the surface disinfectants have verified at least the following spectra of activity: – Bactericidal – Yeasticidal – Virucidal or virucidal against enveloped viruses Follow the manufacturer's instructions for surface disinfectants. Supplement Zeus Infinity Empowered...
  • Page 21 Dräger states that oxygen-releasing agents and chlorine-releasing agents may cause color change in some materials. Color change does not indicate that the product is not functioning correctly. Other surface disinfectants are used at one's own risk. Supplement Zeus Infinity Empowered...
  • Page 22 1 Sterilize the components (maximum 134 °C (273.2 °F), 5 min). 2 Check the components for visible damage and replace if necessary. NOTE Steam sterilization can reduce the life span of the TurboVent 2 blower module. Supplement Zeus Infinity Empowered...
  • Page 23 2 Tighten the quick release screws (A) for the ventilator by turning them 90° clockwise. 4 Tighten the five quick-release screws (B) by turning them 90° clockwise. To do so, use a 6 mm hexagon socket screwdriver (included in the scope of delivery). Supplement Zeus Infinity Empowered...
  • Page 24 30 minutes. – Before inserting the flow sensor check for visible damage and soiling, such as resid- ual mucus, medication aerosols, and parti- cles. – Replace flow sensors when damaged, soiled, or not particlefree. Supplement Zeus Infinity Empowered...
  • Page 25 1 Fit the breathing system (A) on the receiving as it will go. system (B) vertically from above. 2 Lock the breathing system with the two lateral twist locks (C) by turning them as far as they will Supplement Zeus Infinity Empowered...
  • Page 26 If the side openings of the receiving system are covered, this may cause a negative pres- sure in the breathing system and in the pa- tient's lungs. Always make sure that the side openings on the receiving system are not blocked. Supplement Zeus Infinity Empowered...
  • Page 27 4 Label the new water traps in the marked field surement process. It can lead to failure of the gas with the current date. measurement. Risk of device contamination 5 Push the water traps into the holder again until they engage. Supplement Zeus Infinity Empowered...
  • Page 28 Protect water trap (G). Checking the operational readiness Prerequisites: – The device has been assembled and prepared so that it is ready for operation. Procedure:  Check the operational readiness, see instructions for use, chapter "Getting started". Supplement Zeus Infinity Empowered...
  • Page 29 This page has been left blank intentionally. Supplement Zeus Infinity Empowered...
  • Page 30 This page has been left blank intentionally. Supplement Zeus Infinity Empowered...
  • Page 31 This page has been left blank intentionally. Supplement Zeus Infinity Empowered...
  • Page 32 Manufacturer Drägerwerk AG & Co. KGaA Moislinger Allee 53 – 55 D-23542 Lübeck Germany +49 451 8 82-0 +49 451 8 82-20 80 http://www.draeger.com 9510448 – en © Drägerwerk AG & Co.KG Edition: 1 – 2019-04 Dräger reserves the right to make modifications to the device without prior notice.
