Note: please double check if the region settings are set to the region you are located in.
cPRO / cPRO PLUS / cPRO ONE hand unit: double press the HOME button to
•
enter menu; go to MAIN /RADIO / Region to change the region settings. The region will
be set on the cPRO motor automatically.
It may not be legal to operate the cPRO / cPRO PLUS / cPRO ONE hand unit in a country/
region other than the country/region selected in the region menu. Select ROW (Rest of world)
or use the device in hard-wired mode if you are unsure of the correct region setting.
Note: If multiple hand units are used, please set all cPRO / cPRO PLUS / cPRO ONE hand
units you want to connect to the network to the same radio channel as the cPRO motor.
Once a cPRO / cPRO PLUS / cPRO ONE hand unit is set to the same radio channel as the
cPRO motor, the device will connect automatically. Up to 3 cPRO / cPRO PLUS or cPRO
ONE hand units can be connected wirelessly to a cPRO motor at a time. Additional LBUS
control devices including the steady zoom can be hard-wired either to one of the hand units
for wireless operation or directly to the LBUS daisy chain.
7.1.2.2.
• To assign the cPRO motor to the corresponding lens axis, press the upper button
repeatedly until the correct axis name is displayed.
• To assign a cforce mini or cforce plus motor to the corresponding lens axis, press
the FIZ button repeatedly until the correct axis character is illuminated. (F=Focus /
I=Iris / Z=Zoom)
• alternatively, assign the cPRO / cforce motors control axis using the cPRO / cPRO
PLUS / cPRO ONE hand unit; double press the HOME button to enter the adjustment
menu; go to MOTORS / Motor Settings /select the right motor / Axis
7.1.2.3.
• Turn the lens by hand so it is roughly half way between its mechanical end stops
• Engage all motors with the lens and secure firmly
• calibrate the cPRO motor by pressing and holding the upper button for 3 seconds
• calibrate the cforce motors by pressing and holding the FIZ button on each cforce
motor for 3 seconds
• alternatively, calibrate the cPRO / cforce motors using one of the cPRO / cPRO PLUS
/ cPRO ONE hand unit functions „calibrate" e.g. double press the HOME button to
enter the adjustment menu; go to MOTORS / Calibrate all).
Risk of injury! Do not touch the motor gear while motor is moving!
This device is not intended for use by children. Keep body parts out of the motion path.
Disconnect the plug if the device is not used for a longer period of time.
IEC 60417-6056 (2011-05) for other moving parts
All content © 2020, cmotion GmbH. All specifications are subject to change without further notice.
http://www.cmotion.eu

Assigning the cPRO and other motor's control axis

Calibrating the cPRO / cforce motors

NOTICE
CAUTION!
page 105 of 120
