Profile XP
PVS SERIES MEDIA PLATFORMS
System Guide
SOFTWARE VERSION 5.4
071-8289-01
JULY 2004
the mos t watched worl dwide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Profile XP PVS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRASS VALLEY Profile XP PVS Series

Summary of Contents for GRASS VALLEY Profile XP PVS Series

  • Page 1 Profile XP PVS SERIES MEDIA PLATFORMS System Guide SOFTWARE VERSION 5.4 071-8289-01 JULY 2004 the mos t watched worl dwide...
  • Page 2 Broadcast and Media Solutions, Inc., P.O. Box 59900, Nevada City, California 95959-7900 Trademarks Grass Valley, Profile, and Profile XP are either registered trademarks or trademarks of Thomson Broadcast and Media Solutions, Inc. in the United States and/or other countries. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.

  • Page 3: Table Of Contents

    About this manual.........................9 Using the Profile XP Documentation Set .................9 Manual Descriptions ......................10 How this manual is organized..................11 Getting more information ....................12 Grass Valley Product Support ....................13 Safety Summaries General Safety Summary ....................15 Safety Terms and Symbols ....................16 Service Safety Summary ....................17 Certifications and Compliances ..................17...
  • Page 4 Contents Chapter 3 Working with RAID Storage Using GVG Disk Utility RAID chassis product descriptions ..................66 PFC500 product description..................66 PFR500 product description..................66 PFR600 product description..................67 PFR700 product description..................68 Estimating storage capacity ....................69 Determining maximum video data rate per channel............70 Connecting RAID chassis cabling ..................70 Configuring RAID storage using GVG Disk Utility ..............
  • Page 5 Contents Selecting the video I/Os used by a channel ..............157 Selecting video quality for a channel................158 Guidelines for selecting Video Quality Presets............158 Selecting video quality settings for a channel..............160 Selecting browse video quality settings for a channel ..........162 Defining and selecting a custom video quality preset..........164 Recording VBI information uncompressed ...............165 Selecting the video still-play mode ...................169 Viewing video input status....................170...
  • Page 6 Contents Setting up an internal timecode generator ..............217 Recording VITC........................219 Selecting a VITC input for a channel................219 Recording timecode from ancillary data ..............220 Setting up the VITC reader on a Video Input ..............221 Setting up the VITC reader on the Reference Input ............223 Generating VITC on a video output..................225 Selecting the video output as a timecode output for the channel........225 Setting up the VITC generator on a video output ............227...
  • Page 7 Contents Power-on the switch and configure if necessary ............275 Test the Fibre Channel network using Media Manager ..........275 Setting up a simple video network: Ethernet ..............279 Set up the Windows NT Ethernet network..............279 Configure the video network on each Profile XP: Ethernet .........279 hosts Manually Edit the file on each Profile XP............281...
  • Page 8 Contents Making Rack Slide Adjustments ..................336 Mounting Panels and Audio Chassis................337 Rear Panel Drawings .......................338 Profile XP Media Platform Chassis ................338 XLR216 and BNC216 AES/EBU Breakout Panels .............338 PAC216 Profile Audio Chassis..................339 I/O Panel ........................339 PFC500 Fibre Channel RAID Chassis ................340 PFC500E Expansion Chassis ..................340 PFR500 Fibre Channel RAID Chassis ................341 PFR500E Expansion Chassis ..................341...

  • Page 9: Preface

    Preface About this manual This Profile XP System Guide describes the features of the Profile XP Media Platform and presents step-by-step procedures for modifying system settings to meet the specific needs of our system. This manual assumes you have already installed your Profile XP system using the Installation Guide shipped with your unit.

  • Page 10: Manual Descriptions

    Preface Manual Descriptions • (for your Profile XP Model) Provides step-by-step instructions Installation Guide for installing the Profile XP Media Platform using factory default settings for all record/play channels. Factory default settings are indicated within the guide. After installing the Profile XP system using this installation guide, you can refer to this Profile XP System Guide to customize system settings for your installation.

  • Page 11: How This Manual Is Organized

    How this manual is organized How this manual is organized The Profile XP System Guide is organized around the tasks you’ll be performing to customize the Profile XP settings to meet your system needs. You can see this reflected in the chapter titles chosen for this manual. The following identifies and describes the chapters included in this manual: Chapter 1 - Introducing the Profile XP Media Platform Introduces the Profile XP Media Platform.

  • Page 12: Getting More Information

    Preface Appendix B - Connector Pin-outs This appendix identifies connectors and the signals present on the pins of those connectors. Appendix C - Rack Mounting Information and Rear Panel Drawings This appendix provides rack mounting information for the Profile XP system and peripheral equipment.

  • Page 13: Grass Valley Product Support

    Grass Valley Product Support To get technical assistance, check on the status of problems, or report new problems, contact Grass Valley Product Support via e-mail, the Web, or by phone or fax. Web Technical Support To access support information on the Web, visit the product support Web page on the Grass Valley Web site.
