GASOLINE GENERATOR
TP18001
TP18001-5
UTP18001
800W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP18001 and is the answer not in the manual?

Questions and answers

Kouame koffi Emmanuel
March 15, 2025

I have a problem with my tp18001 gasoline generator, it smokes and stops after 10 minutes in starting, I recognise to have not understood the necessary oil level, I put too much, but how I settle this problem

0

Subscribe to Our Youtube Channel

Related Manuals for Total TP18001

Summary of Contents for Total TP18001

  • Page 1 One-Stop Tools Station GASOLINE GENERATOR TP18001 TP18001-5 UTP18001 800W...
  • Page 2 FOREWORD DANGER Indicates a possibility of death or serious injury if instructions are not followed. WARNING Indicates a strong possibility of severe personal injury, loss of life and equipment damage if instructions are not followed. CAUTION Indicates a possibility of personal injury or equipment damage if instructions are not followed.

  • Page 3: Safety Instructions

    1. SAFETY INSTRUCTIONS Please make sure you review each precaution carefully. WARNING Do not operate the generator near gasoline or gaseous fuel because of the potential danger of explosion or fire. Do not fill the fuel tank with fuel while the engine is running. Do not smoke or use open flame near the fuel tank.
  • Page 4 WARNING Do not operate in rain, in wet or damp conditions, or with wet hands. The operator may suffer severe electric shock if the generator is wet due to rain or snow. WARNING If wet, wipe and dry it well before starting. Do not pour water directly over the generator, nor wash it with water.

  • Page 5: Specifications

    2. SPECIFICATIONS TP18001 TP18001-5 MODEL UTP18001 Brushless, single phase Type Voltage regulating system Capacitor AC Output Rated voltage-Frequency V-Hz 220-240~50 220-240~60 110-120~60 Max. / Rated current 3.3 / 2.8 6.7 / 5.4 Max. / Rated output 800 / 650 800 / 650...
  • Page 6 3. COMPONENTS TP18001, UTP18001 Handle Fuel cap Fuel tank Recoil starter handle Engine on-off switch Choke lever Air filter housing AC socket Reset button 10. Exhaust 11. Motor cover 12. DC socket 13. DC charging leads 14. Spark plug wrench...
  • Page 7 4.FUELING The generator is powered by a two-stroke engine, which uses a petrol and oil mix fuel. The correct fuel mixture is a ratio of 50:1 petrol and two stroke oil. WARNING Use only genuine two-stroke oil. Fuel mixing The fuel tank has a maximum capacity of 4.0L (1.06gal). To mix the fuel correctly use the filler cap gauge to measure the correct amount of oil to petrol.
  • Page 8 "LEVEL" position : (L/Gal) TP18001 ....4 /1.06 TP18001-5....4 /1.06 UTP18001 .

  • Page 9: Grounding The Generator

    CHECKING COMPONENT PARTS Check following items before starting engine: Fuel leakage from fuel hose, etc. Bolts and nuts for looseness. Components for damage or breakage. Generator not resting on or against any adjacent wiring. CHECK GENERATOR SURROUNDINGS WARNING Make sure you review each warning in order to prevent fire hazard. Keep area clear of in flammables or other hazardous materials.

  • Page 10: Operating Procedures

    5. OPERATING PROCEDURES STARTING THE GENERATOR CAUTION Check the fuel level before each operations as outlined by the article "CHECK MIXED FUEL" (a) Turn the Engine switch to the position "ON". (b) Open the fuel valve to position "ON". (c) Pull the starter handle slowly until passing the compression point (resistance will be felt), then return the handle to its original position...

  • Page 11: Using Electric Power

    Check the amperage of the receptacles used referring to TABLE 1, and be sure not to take a current exceeding the specified amperage. Be sure that the total wattage of all appliances dose not exceed the rated output of the generator.
  • Page 12 Stop the generator immediately, check the appliance and / or generator for overloading or detect and have repaired as necessary by TOTAL dealer or service shop. (c) Turn on the switch of the appliance.

  • Page 13: Stopping The Generator

    STOPPING THE GENERATOR (a) Turn off the power switch of the electric equipment and unplug the cord from receptacle of the generator. (b) Allow the engine about 3 minutes to cool down at no-load before stopping. (c) Turn the engine switch to the position. (d)Close the fuel valve.

  • Page 14: Wattage Information

    Depending on their wattage output, generators will run anything from a small lamp to a number of large appliances. To determine the size generator you will need, total the wattage of the maximum number of items you will be running simultaneously.
  • Page 15 Don't just add up the total wattage for everything you want to power. See our section on power management to learn how to use a smaller generator to power more. See the chart below to estimate your power needs. Home Applications...
  • Page 16 Approximate Approximate Starting Wattage Running Wattage element) Automatic Washer 1200 1200 Clothes Dryer (Electric) 6750 5400 Radio 50 to 200 50 to 200 Sump Pump 1/3 Horsepower 1300 1/2 Horsepower 2150 1050 Window Air Conditioner 2200 1500 (10,000 BTU) Computer Laptop 200-250 200-250...
  • Page 17 Approximate Approximate Starting Wattage Running Wattage Radiant Heater 1300 1300 Laptop computer 200-250 200-250 Satellite Receiver Radio 50 to 200 50 to 200 Two-Way Radio 360W 360W 840W 840W 960W 960W Fan (portable) DVD Player Contractor Applications Approximate Starting Approximate Running Wattage Wattage Air Compressor...
  • Page 18 Approximate Starting Approximate Running Wattage Wattage Table Saw (10 in.) 4500 1800 Industrial Motors Split Phase 1/8 Horsepower 1200 1/4 Horsepower 1700 1/3 Horsepower 1950 1/2 Horsepower 2600 Capacitor Start Induction Run 1/8 Horsepower ¼ Horsepower 1050 1/3 Horsepower 1350 ½...
  • Page 19 Farm Equipment Approximate Starting Approximate Running Wattage Wattage Electric Fence, 25 miles Milk Cooler 1800 1100 Milker (vacuum pump, 2300 1000 2hp) Portable Heater (kerosene, diesel fuel) 50,000 BTU 90,000 BTU 150,000 BTU 1000 Battery Charger 15 amp 60 amp with 250-amp 1500/5750 1500/5750 boost...

  • Page 20: Maintenance Schedule

    7. MAINTENANCE SCHEDULE DAILY INSPECTION Before running the generator, check the following service items: Enough mixed oil PERIODIC MAINTENANCE Periodic maintenance is vital to safe and efficient operation of your generator Check the table below for periodic maintenance intervals. IT IS ALSO NECESSARY FOR THE USER OF THIS GENERATOR TO CONDUCT THE MAINTENANCE AND ADJUSTMENTS ON THE EMISSION- RELATED PARTS LISTED BELOW TO KEEP THE EMISSION CONTROL SYSTEM EFFECTIVE.
  • Page 21 Periodic Maintenance Schedule table Every Every Every Every Every Maintenance Items 8 hours 50 hours 200 hours 1000 (Daily) (Weekly) (Monthly) hours hours (Daily) Clean generator and check bolt and nuts (Refill daily up to upper level) Check and refill engine oil (Initial (Every Change engine oil (*Note1)

  • Page 22: "How-To" Maintenance

    8. "HOW-TO" MAINTENANCE CLEANING AND ADJUSTING SPARK PLUG (a) If the plug is contaminated with carbon, remove it using a plug cleaner or wire brush. (b) Adjust the electrode gap to 0.6 to 0.7 mm (0.024 to 0.028 in.). Gap 0.6 to 0.7 mm ( 0.024 to 0.028 in.

  • Page 23: Troubleshooting

    9. TROUBLESHOOTING When generator engine fails to start after several attempts, or if no electricity is available at the output socket, check the following chart. If your generator still fails to start or generate electricity, contact your nearest dealer or service shop for further information or corrective procedures.
  • Page 24 TP18001,TP18001-5,UTP18001 Spare part list - Engine Part No. Part Description Part No. Part Description Crankcase(A) 1.1.1 1.1.37 Washer Bearing 1.1.2 1.1.38 Nut M6 1.1.3 Crankshaft 1.1.39 Air shroud 1.1.4 Dowel pin 1.1.40 Screw M6×10 1.1.5 Crankcase 1.1.41 Clamp Oil seal 1.1.6...
  • Page 25 TP18001,TP18001-5,UTP18001 Exploding view - Engine...
  • Page 26 TP18001,TP18001-5,UTP18001 Spare part list - Generating Setassembly Part No. Part Description Part No. Part Description Engine 1.34 Slator assembly Screw M6×18 1.35 Carburetor Exhaust gasket 1.36 Carburetor spring Muffler 1.37 Carburetor Screw M6×12 1.38 Carburetor Clip 1.39 Carburetor Fuel hose 1.40...
  • Page 27 TP18001,TP18001-5,UTP18001 Exploding view - Generating Setassembly...
  • Page 28 One-Stop Tools Station GASOLINE GENERATOR www.totaltools.cn TOTAL TOOLS CO.,LIMITED MADE IN CHINA T0816.V11 800W...

This manual is also suitable for:

Tp18001-5Utp18001
