Summary of Contents for PATROLLINE HPS 930
- Page 1 HPS 930 12 - . 0 – HPS 930 ING...
- Page 2 Foreword… The HPS 930 is an alarm for scooters and motorcycles, it’s suitable for the vehicle with the original immobilizer system. It’s a device completely automatic and it’s widely programmable to adapt to many different needs.
-
Page 3: Conformity Declaration
Battery backup… HPS 930 is equipped with buffer batteries that guarantee its operation also in the case the cable that connects the battery to the electric plant of the vehicle is cut. The battery backup is automatically armed when the black connector of the alarm wiring is connected. - Page 4 Setting functions… To set the HPS 930 functions, it’s necessary turn ON and OFF the key as many times as the value of the desired function. (look at the tabel following). It’s possible to set the function when the alarm is disarmed.
- Page 5 The system has an additional alarm output, it’s activated only in case of alarm. It’s possible to convert the output to modules command, it’s turned ON when the system is inserted and turned OFF when the system is disarmed. 12 - . 0 – HPS 930 ING...
- Page 6 When you have the turn key ON, the procedure exit will be without modify the previous level (abort). The procedure exit is signalled with the led turn OFF. 9. Backup If you turn ON and OFF the ignition key 20 times, it will restore the original level and regulation. 12 - . 0 – HPS 930 ING...
- Page 7 A progressive diminution of the transmission range, means that the remote-control battery is unloading. Replace the battery immediately will avoid to have the alarm inserted and the remote control unusable. 12 - . 0 – HPS 930 ING...
- Page 8 (1) Blue Negative alarm input Stand push-button Negative input for the (10) Grey/Black anti-theft push-button (5) Brown Alarm NEGATIVE output (9) Brown/Black (12) Brown/White (max 100mA) Positive power output for the indicator lights 12 - . 0 – HPS 930 ING...
-
Page 9: Standard Connection
GREY/BLACK MOTORCYCLE PLANT “LED I ” AT THE CONNECTION AND VERIFY THAT THE MMOBILIZER OPERATES Immobilizer CORRECTLY ’ GREY/BLACK F IT DOESN T OPERATE YOU MUST INVERT THE WIRE WITH BLACK WIRE 12 - . 0 – HPS 930 ING... - Page 10 If you compose the N° 19 code you’ll active the TEST LED procedure, when the LED is ON the alarm gives an acoustical signal that indicates the correct reading. To stop the procedure, it’s necessary to turn OFF the ignition key. 12 - . 0 – HPS 930 ING...
- Page 11 The warranty consists in free replacing or repairing of parts unusable or inefficient because of factory’s fault verified by Patrolline. Any delay in carrying out works do not entitle to damages or extension of warranty. The warranty lapses if the devices are used not in conformity with the present conditions, if they are modified, repaired or tampered, if the defects derive from accidents, from negligence or from using parts not original.
-
Page 12: Installation Certificate
MALFUNCTION (minutely describe the problem): _______________________________________________________________ _______________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ PATROLLINE GROUP Società Cooperativa Via C. Cantù 15/C 22031 Albavilla (CO) ITALY Tel: +39.031.0352088 Fax: +39.031.0352089 E-mail: Web: info@patrolline.it www.patrolline.it 12 - . 0 – HPS 930 ING...
