cinetto B-MOVED PS40 Quick Use Manual
Wave sensor
Hide thumbs
Also See for B-MOVED PS40:
- Assembly instructions manual (12 pages) ,
- Assembly instructions manual (120 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for cinetto B-MOVED PS40
Summary of Contents for cinetto B-MOVED PS40
- Page 1 Quik use guide...
- Page 2 English All dimensions in this leafl et are stated in millimeters. WARNING Do not use any anti-friction oil or grease or thread-realese spray on ball bearing or on wheels with O-ring, it can cause the mel- ting of the inside ball bearing grease, ma- king them noisy or causing the break of the O-ring of the wheels.
- Page 3 Before installing Wave Sensor, it is necessary to have installed the B-moved electrical system. PS40 & B-MOVED CONFIGURATION...
- Page 4 CONFIGURATION...
- Page 5 CONFIGURATION W1 = SYNCHRONIZED OPENING...
- Page 6 W1 = SYNCHRONIZED OPENING...
- Page 7 CONFIGURATION W1, W4 = SYNCHRONIZED OPENING W1 = SYNCHRONIZED OPENING...
- Page 8 W1, W4 = SYNCHRONIZED OPENING...
- Page 9 PS48 & B-MOVED CONFIGURATION...
- Page 10 CONFIGURATION *Central door opening just to the left.
- Page 11 CONFIGURATION W1 = SYNCHRONIZED OPENING...
- Page 12 W1 = SYNCHRONIZED OPENING...
- Page 13 CONFIGURATION W1, W4 = SYNCHRONIZED OPENING W1 = SYNCHRONIZED OPENING...
- Page 14 W1, W4 = SYNCHRONIZED OPENING...
- Page 15 Wireless proximity sensor Max recommended distance between receiver unit and sensor: 10 meters. Up to 10 sensors each door. Battey not included. 2 x AAA 1,5V for each sensor.
- Page 16 Wave Sensor positioning MAX 10 MAX 10 MAX 10 Do not place Wave Sensor behind metallic, conductive materials or mirrors. 71,5 option 68,5...
- Page 17 1. Pairing To start the procedure, press and hold the button for the channel you want to confi gure (“SENSOR SET A” or “SENSOR SET B”) for two seconds, the corresponding LED will start to fl ash. 00:00:02...
- Page 18 Touch the sensor you want to pair, this will be immediately recognised, causing the LED to fl ash quickly twice before turning off. At this point the procedure is completed and the devices are correctly paired. • Up to 10 different sensors can be paired with each channel. •...
- Page 20 It must be installed following the original instructions inside the package brackets for fi xing the upper slides to the B-MOVED system. Code: PS40KM10002P0002, PS48KM10002P0001, PS48KM10002P0002, PS48KM10003P0001. Cinetto F.lli S.r.l. Via Rossi, 5/A 35030 Rubano (PD) Italy Tel. +39 049 8977211 Fax +39 049 635822 www.cinetto.it...
