- Page 1 Quik use guide...
- Page 2 English All dimensions in this leaflet are stated in millimeters. WARNING Do not use any anti-friction oil or grease or thread-realese spray on ball bearing or on wheels with O-ring, it can cause the mel- ting of the inside ball bearing grease, ma- king them noisy or causing the break of the O-ring of the wheels.
- Page 3 Before installing Wave Sensor, it is necessary to have installed the B-moved electrical system. PS40.3 CONFIGURATION...
- Page 4 CONFIGURATION CONFIGURATION...
- Page 5 PS48.2 CONFIGURATION...
- Page 6 CONFIGURATION *Central door opening just to the left.
- Page 7 CONFIGURATION...
- Page 8 Wireless proximity sensor Max recommended distance between receiver unit and sensor: 10 meters. Up to 10 sensors each door. Battey not included. 2 x AAA 1,5V for each sensor.
- Page 9 Wave Sensor positioning MAX 10 MAX 10 MAX 10 Do not place Wave Sensor behind metallic, conductive materials or mirrors. 71,5 option 68,5...
- Page 10 1. Pairing To start the procedure, press and hold the button for the channel you want to configure (“SENSOR SET A” or “SENSOR SET B”) for two seconds, the corresponding LED will start to flash. 00:00:02...
- Page 11 Touch the sensor you want to pair, this will be immediately recognised, causing the LED to flash quickly twice before turning off. At this point the procedure is completed and the devices are correctly paired. • Up to 10 different sensors can be paired with each channel. •...
- Page 12 Cinetto F.lli S.r.l. Via Rossi, 5/A 35030 Rubano (PD) Italy Tel. +39 049 8977211 Fax +39 049 635822 www.cinetto.it info@cinetto.it...
