7.4 PARALLEL DRIVE GEARBOX

40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
©Copyright Task Force Tips, Inc. 2010
A1633 PARALLEL DRIVE GEARBOX SUBASSEMBLY
ITEM DESCRIPTION
40 KNOB
41 1/4-20 X 1/2 SCREW
60
42 CRANK
43 CRANK BUSHING
44 WASHER
45 3/8-16 X 1-1/2 SCREW
61
46 GEARBOX
47 O-RING-116
48 SPACER
62
49 DRIVE SHAFT
63
50 NYLON BUSHING
51 GEAR BUSHING
52 DOUBLE GEAR
64
53 TRUNNION BUSHING
54 INNER TRUNNION
55 DOWEL PIN
56 O-RING-154
65
57 SUBPLATE
58 O-RING-028
66
59 INNER BUSHING
HANDLE LABEL - BLUE
60 HANDLE LABEL - RED
HANDLE LABEL - WHITE
61 10-24 3/8 SCREW
62 WASHER
63 POSITION INDICATOR
64 LABEL
65 O-RING 206
66 INDICATOR GEAR
67 O-RING 214
68 1/4-20 X 3/4 SCREW
67
68
11
QTY PART #
1 A1512
2 VT25-20BH500
1 A1559
1 A1513
1 VW812X406-65
1 VT37-16BH1.5
1 A1550
1 VO-116
1 A1556
1 A1555
1 AY307
1 A1548
1 A1554
1 A1549
1 A1553
2 VP312X.50
1 VO-154
1 A1551
1 VO-028
1 A1552
AY342-BLU
1 AY342-RED
AY342-WHT
1 VT10-24BH375
1 VW500X203-60
1 A1558
1 A2011
1 VO-206
1 A1557
1 VO-214
1 VT25-20SH750
LIA-420 July 12, 2010 Rev00
