INSTALLATION
GUIDE
MFR-9SDI12GA
MFR-9SDO12GA
MFR-9SDI
MFR-9SDO
rd
3
Edition

Advertisement

loading
Need help?

Need help?

Do you have a question about the MFR-9SDI12GA and is the answer not in the manual?

Questions and answers

Summary of Contents for FOR-A MFR-9SDI12GA

  • Page 1 INSTALLATION GUIDE MFR-9SDI12GA MFR-9SDO12GA MFR-9SDI MFR-9SDO Edition...
  • Page 2 Upon Receipt MFR-9SDI12GA/9SDO12GA cards and their accessories are fully inspected and adjusted prior to shipment. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately.
  • Page 3 Before Starting MFR-9SDI12GA/MFR-9SDI is an input card for MFR-4100/MFR-6100 units. MFR-9SDO12GA/MFR-9SDO is an output card for MFR-4100/MFR-6100 units. Open the front panel and see the product label as shown below to identify the card type.
  • Page 4 MFR-9SDI card. as shown below (viewed from the rear). If an MFR-9SDI12GA is installed into a slot located just left of an MFR-9SDI, BNC cables cannot be connected or BNC connectors or BNC cables may be damaged.
  • Page 5 (Slot No.17 to 20 and 29 to 32) slots: Do not install MFR-9SDI12GA cards just left (viewed from the rear) of an MFR-9SDI card. If an MFR-9SDI12GA is installed into a wrong slot, BNC cables cannot be connected or BNC connectors or BNC cables may be damaged.
  • Page 6 1. Matrix Size Chart 1-1. MFR-4100 Matrix size varies depending on the number of installed MFR-9SDI12GA/9SDI and MFR- 9SDO12GA/9SDO cards as shown below. (72 x 72 to 9 x 9) Number of cards: MFR-9SDO12GA / MFR-9SDO 72 x 72 72 x 63...
  • Page 7 1-2. MFR-6100 Matrix size varies depending on the number of installed MFR-9SDI12GA/9SDI and MFR- 9SDO12GA/9SDO cards as shown below. (144 x144 to 9 x 9) Number of cards: MFR-9SDO12GA / MFR-9SDO...
  • Page 8 2. [MFR-4100] I/ O Cards Installation / Replacement IMPORTANT Contact FOR-A agent of service center for I/O Card installation and replacement work since such work should only be conducted by qualified technical personnel. 2-1. Checking Installation Slots When installing both MFR-9SDI and MFR-9SDI12GA cards, there are installation restrictions.
  • Page 9 2-2. How to Install a New Card The following procedure shows how to install an output card into OUTPUT1 slot. (1) Unfasten four fixing screws on the front panel and detach the front panel. POWER POWER 2 POWER 1 CP U1 CP U2 MFR -4100 ROUTING SWITCHER...
  • Page 10 (7) Check whether OUTPUT1 slot status is normal using [STATUS > SLOT] menu in Menu display. (After installing the card, it takes about 10 seconds for the status to be applied in the menu.) (See Sec. 4-1-4. “STATUS > SLOT” in the MFR-4100 Operation Manual for details.) (8) Re-install the front panel.
  • Page 11 2-3. How to Replace a Card The following procedure shows how to replace the card in INPUT1 to a new input card. (1) Detach all the BNC cables connected to the INPUT1 connector ports. FAN 1 FAN 2 FAN 3 REF IN ALARM 23 2C...
  • Page 12 3. [MFR-6100] I/ O Card Installation / Replacement 3-1. Checking Installation Slots When installing both MFR-9SDI and MFR-9SDI12GA cards, there are installation restrictions. To properly function cards, locate the right place for installing cards. If these cards are installed in wrong slots, BNC cables cannot be connected or BNC connectors or BNC cables may be damaged.
  • Page 13 3-2. How to Install a New Card The following procedure shows how to install an output card into OUTPUT1 slot. (1) Unfasten four fixing screws on the front panel and detach the front panel. POW ER CPU2 CPU1 MFR-6100 ROUTING SW ITCHER POWER 1 POWER 2 (2) Remove the two screws on both sides of...
  • Page 14 (6) Turn the OUTPUT1 slot ON using [SETTING > SLOT SHUTDOWN] menu in Menu display. (See Sec. 4-2-2. “Turning ON/OFF an Input/ Output Card” in the MFR-6100 Operation Manual for details.) (7) Check whether OUTPUT1 slot status is normal using [STATUS > SLOT] menu in Menu display. (After installing the card, it takes about 10 seconds for the status to be applied in the menu.) (See Sec.
  • Page 15 3-3. How to Replace a Card The following procedure shows how to replace the card in INPUT1 slot to a new input card. FAN 5 FAN 6 (1) Detach all the BNC cables REF IN CPU1 CPU2 ALARM MFR-LAN PC-LAN MFR-LAN PC-LAN 232C...
  • Page 16 Tel: +1 352-371-1505 Fax: +1 714-894-5399 FOR-A Latin America and the Caribbean Miami Office Tel: +1 657-600-5759 FOR-A Latin America and the Caribbean Sao Paulo Office Tel: +55 (0)11-99913-3751 FOR-A Europe S.r.l. Via Volturno, 37, 20861 Brugherio MB, Italy Tel: +39 039-916-4811...
