- Page 1 INSTALLATION GUIDE HVS-100ARC ARCNET Card Edition...
- Page 2 Upon Receipt Unpacking HVS-100ARC cards and their accessories are fully inspected and adjusted prior to shipment. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately.
- Page 3 Table of Contents 1. Installing the HVS-100ARC ....................... 4 1-1. Installing the Arcnet Card into your HVS-100 ..............4 1-2. Installing the Arcnet Card into your HVS-110 ..............7 2. Checking the Status Menu ...................... 10...
-
Page 4: Installing The Hvs-100Arc
1. Installing the HVS-100ARC The procedure below describes how to install an optional Arcnet card into an HVS-100 or HVS-110 unit. Installing this option requires the unit interior to be accessed by opening the panel. Installation should only be performed by qualified technical personnel. - Page 5 (4) Unpack the Arcnet card (HVS-100ARC) and flex cable, and connect the cable to the card following Steps (a) to (d). Stopper Arcnet card (a) Gently grab the stopper by both sides and pull it straight up. (c) Vertically insert the cable...
- Page 6 (8) Replace and secure the top panel back onto the chassis with its five screws. (9) Attach the supplied HVS-100ARC rating label on the rear panel as indicated in the figure below. REF IN REF OUT GENLOCK SDI INPUT HDMI OUT...
-
Page 7: Installing The Arcnet Card Into Your Hvs-110
1-2. Installing the Arcnet Card into your HVS-110 (1) Power Off your HVS-110 and disconnect the power cord(s). (2)Remove the five screws from on the back of the control panel on the front side of the HVS-110. (3) Remove the three screws (circled) from the HVS-110 rear panel as shown. POWER MODE SW DC12V IN... - Page 8 (6) Unpack the Arcnet card (HVS-100ARC), shield plate and four W-sems screws and secure the shield plate to the back of the card with the four screws as shown below. Arcnet card Shield plate (7) Unpack flex cable, and connect them as shown below. Follow Step (4) in section 1-1 to connect the flex cable to the card.
- Page 9 (12) Replace and secure the top panel back onto the chassis with the screws removed in Steps (2) and (3). (13) Attach the supplied HVS-100ARC rating label on the rear panel as indicated in the figure below. POWER MODE SW...
-
Page 10: Checking The Status Menu
2. Checking the Status Menu Follow the procedure below to verify that the Arcnet card (HVS-100ARC) has been properly installed. (1) The MENU button on the control panel should blink when powered ON. (2) Press MENU, then press SETUP. (3) The SETUP menu top page appears in the menu display. Turn F1 to select STATUS and then press F1. - Page 11 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 12 Tel: +1 352-371-1505 Fax: +1 714-894-5399 FOR-A Latin America and the Caribbean Miami Office Tel: +1 657-600-5759 FOR-A Latin America and the Caribbean Sao Paulo Office Tel: +55 (0)11-99913-3751 FOR-A Europe S.r.l. Via Volturno, 37, 20861 Brugherio MB, Italy Tel: +39 039-916-4811...
