- Page 1 DIGIPOWER 4x150T/02 POWER AMPLIFIER MANUAL Designed and Manufactured by ITEC Tontechnik und Industrieelektronik GesmbH 8200 Laßnitzthal 300 Austria / Europe DIGIPOWER 4X150T/02_EN_2016/05_REV_2020/02...
-
Page 2: Dear Customer
ITEC DIGIPOWER 4x150T/02 - INTRODUCTION Dear Customer! The power amplifi ers of the series “ITEC DigiPower” offer due to the latest digital technology in place an extremely high effi ciency. Another feature is the very low power consumption in the automatic standby mode. -
Page 3: Safety Instructions
ITEC DIGIPOWER 4x150T/02 Safety instructions Please read this instruction manual carefully before installation and putting the “ITEC DigiPower” amplifi er into operation. Keep this document easy to fi nd on a safe place to have it available as a later reference. - Page 4 ITEC DIGIPOWER 4x150T/02 - FRONT VIEW 1. 24V DC: indicates that 24V DC power is applied 2. 230V AC: indicates that the applied voltage is 230V AC. The device is supplied by this voltage - the 24V DC remains unloaded.
- Page 5 ITEC DIGIPOWER 4x150T/02 Connection example Channel 1 OUT 1 0/ 50V/100V +IN 1 Signal 1 Input -IN 1 100 V / Σ 150 W / 66 Ω (50 V / 16 Ω) www.itec-audio.com DIGIPOWER 4X150T/02_EN_2016/05_REV_2020/02...
- Page 6 ITEC DIGIPOWER 4x150T/02 - BACK VIEW 8. 230VAC: The power cord is plugged in to the panel connector containing an integrated fuse (6A). The device becomes active, when a voltage of 230V AC is applied 9. DC IN 24V: The 24V DC power supply is connected to the terminal block. In case of a breakdown of the 230 V supply a switch to the 24V DC supply is carried out without interruption.
- Page 7 ITEC DIGIPOWER 4x150T/02 26. Bridge B Active: Chanel 1/2 Bridge mode, if closed 27. Bridge B Active: Chanel 3/4 Bridge mode, if closed 28. Address (optional): Input of device address for serial control command 29. Power Delay Link: For cascadeable switch-on delay when using several power amplifi ers on one 230V AC supply.
- Page 8 19“ / 2 RU (482 mm x 88 mm x 302mm) Weight 17.1 kg All Informations without garantee. Subject to technical changes. ITEC-Tontechnik und Industrieelektronik GesmbH, A-8200 Gleisdorf, Lassnitzthal 300 Tel.: +43 (0)3133 / 3780-0, offi ce@itec-audio.com, www.itec-audio.com DIGIPOWER 4X150T/02_EN_2016/05_REV_2020/02...
