- Page 1 FINDER GPS Navigation Bike Computer APP Download Quick User Guide...
-
Page 2: Table Of Contents
Menu(English) How to install?..................02 GPS Working Status.................. 3 APP Connec on..................03 Naviga on Guide..................04 Start To Use....................06 Bu on Func ons..................09 Icons & abbrevia ons and its meanings........... 10 Wireless Connec on Protocols..............11 Data Upload..................... 12 Charge...................... 13 Specifica on.....................13 Safety Statement And Warranty............... -
Page 3: How To Install
English FINDER GPS Naviga on Bike Computer How to install? F-Mount Device Data Cable Rubber Band Bike Mount Screw -02-... -
Page 4: Gps Working Status
A er installing the MEILAN APP and signing up, please turn on the Bluetooth and loca on func ons of the phone, connect the APP to FINDER , and then you can use the APP to set up FINDER and connect / delete sensors and etc. -
Page 5: Naviga On Guide
Naviga on Guide In order to ensure the accuracy and professionalism, FINDER is directly conneted with the world-renowned outdoor naviga on company KOMOOT APP for naviga on. 1.Please download KOMOOT APP from Google Play or Apple Store, install it into your computer, and follow the APP instruc ons to register an account. - Page 6 Off Exit Off Wait for FINDER and KOMOOT to connect successfully. If a pairing request dialog pops up on the phone during this process, Please confirm the request. FINDER is connec ng with KOMOOT (Figure G-1) The phone system requires authoriza on for pairing (Figure G-2)
-
Page 7: Start To Use
Start to use Language Start to use and sensor pairing English 1.Long press toswitch on FINDER . 2.You need to set up your FINDER when it is used at first me. ①Language se ng(Figure H-1) -06- -03-... - Page 8 ⑤ODO Ini al total mileage se ng(Figure H-5) ⑥Start to pair sensors(Figure H-6) First make sure that the ba ery of the sensor that you want to connect to the FINDER is in the normal opera ng state. Please also assure that the installa on and wearing posi on is correct, as the sensors are normally in power saving mode.
- Page 9 Long press bu on to save this me cycle data. 6.Then FINDER will automa cally enter into the history record menu. If you do not want to view the history, you can short press bu on to exit the history menu or directly turn off...
-
Page 10: Bu On Func Ons
Bu on Func ons Press: Power switch key. Short press: Enter into the working status (Figure A) Short press: Increase / Up, Short press: Decrease / Down. 10:12 Mon, Nov 27 Short press: Short press: in riding state: segment (LAP). Please note: The segmenta on (LAP) func on only can be used when you start recording. -
Page 11: Icons & Abbrevia Ons And Its Meanings
Icons & abbrevia ons and its meanings Short press enter GPS is located Bluetooth open H: M 10:12 Week,Date Mon, Nov 27 Ba ery power Speed sensor is not connected Backlight brightness Cadence sensor is not connected Heart rate belt is not connected Power meter is connected Status page query: short press ;... -
Page 12: Wireless Connec On Protocols
Short press to confirm, short press to select the next item, short press back to previous page. FINDER can change the name of the data that displaying on the screen. Enter se ngs,select Setting Datamanagement Speed Distance Ac.Time... -
Page 13: Data Upload
USB cable to copy out the sports files via the USB interface and upload them to website. 1.In the off state, plug in the USB data cable. 2. Open your removable storage disk on the computer:(MEILAN- FINDER folder: ACTIVITY. -
Page 14: Charge
Charge Input:： MircoUSBDC5V/0.5A Specifica on 1. Ba ery type: Rechargeable lithium ba ery 2. Working hours: 25 hours 3. Wireless transmission mode: Bluetooth BLE4.0 / ANT + 4. Opera on frequency: 2.4G HZ 5. Ambient temperature: -10℃ — + 40 ℃ 6. -
Page 15: Access To Faq & Videos
You can contact the a er-sales service through MEILAN global distributors or by wri ng to MEILAN. When sending for repairs, you need to effec vely keep the internal storage informa on. Data may be lost during the repair process.
