Snapper NSPV21675 Parts Manual
21" variable speed rear discharge mowers
Hide thumbs
Also See for NSPV21675:
- Parts manual (22 pages) ,
- Safety instructions & operator's manual (48 pages) ,
- Safety instructions & operator's manual (48 pages)
Advertisement
Parts Manual for
21" VARIABLE SPEED
REAR DISCHARGE MOWERS
MODEL
NSPV21675 (7800231)
NSPV21675E (7800232)
SPV21675 (7800179)
SPV21675E (7800195)
Briggs & Stratton Yard Power Products Group
535 Macon Road
Manual No.
7102346
McDonough, GA, 30253 U.S.A.
800-935-2967
Revision C,
4/23/2008
TP 400-5362-C-WB-N
Advertisement
Related Manuals for Snapper NSPV21675
Summary of Contents for Snapper NSPV21675
- Page 1 Parts Manual for 21" VARIABLE SPEED REAR DISCHARGE MOWERS MODEL NSPV21675 (7800231) NSPV21675E (7800232) SPV21675 (7800179) SPV21675E (7800195) Briggs & Stratton Yard Power Products Group 535 Macon Road Manual No. 7102346 McDonough, GA, 30253 U.S.A. 800-935-2967 Revision C, 4/23/2008 TP 400-5362-C-WB-N...
-
Page 3: Table Of Contents
PAGE GROUP Handles and Controls (SPV21) Deck Assembly (SPV21) Engine and Blade Assembly (SPV21) Front and Rear Wheels (SPV21) Transmission (21") Decals (21") Wiring Schematic 21" VARIABLE SPEED Table Of Contents Manual No. 7102346 TP 400-5362-C-WB-N... - Page 4 Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N...
-
Page 5: Handles And Controls (Spv21)
Handles and Controls (SPV21) Item Part No Description 7100225 SCREW, #8-16 Torxplus Recessed Pan Head, Twin Helix 7300670A PLATE, Control Panel- Plastic Handle 2860694 NUT, 1/4-20, Hex Flange Nyloc 7101410 ROPE GUIDE (1/4-20 thread) 7101312 HANDLE, Plastic Upper, WBM 7101321BH BAIL, Plastic Handle, WBM 7101416 ASSY, Control Head, 21”... -
Page 6: Deck Assembly (Spv21)
Deck Assembly (SPV21) Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N... - Page 7 Deck Assembly (SPV21) Item Part No Description 7101490 CHUTE, 21” Side Discharge 7091020 PUSHNUT, 1/4” 7101471 ROD, Pivot, Mulch Cover 722507 SPRING, Torsion, Chute 722848 SCREW, 1/4-20 x 11/16” Pan Head Torx, Self-Tap 7101437 COVER, 21” Mulching 7300590D BRACKET, Chute Deflector 7091286 SCREW, #10-24 x 1/2”...
- Page 8 Deck Assembly (SPV21) Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N...
- Page 9 Deck Assembly (SPV21) Item Part No Description 7300585D BAFFLE, Front 21” WBM, RD 724970 LEVER, Spring Height-of-Cut 724887 GRIP, Height-of-Cut 7400203D WELDMENT, Rear Crossbar 21” WBM, RD 7023590 COTTER, 1/4” Self-Lock 7400247 WELDMENT, Lifter Link, 21” WBM, RD 7101241 BUSHING, Front, 21” 7091892 PUSHNUT, 1/4 Black 7400204D...
-
Page 10: Engine And Blade Assembly (Spv21)
Engine and Blade Assembly (SPV21) Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N... - Page 11 Engine and Blade Assembly (SPV21) Item Part No Description * ENGINE, B&S, X-Spec Mod. 126T02-0675-B3 * ENGINE, B&S, ES Mod. 126T05-0678-B3 * ENGINE, B&S, X-Spec Mod 126T02-0177-B1 7090324 SCREW, 3/8-16 x 1” Hex Washer Self-Tap 7300725D BELT GUARD 7300724D COVER, Belt 7091200 SCREW, 1/4-20 x 1/2”...
-
Page 12: Front And Rear Wheels (Spv21)
Front and Rear Wheels (SPV21) Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N... - Page 13 Front and Rear Wheels (SPV21) Item Part No Description 7100861 PIN, Axle 727782 SHIELD, Axle 7400203D WELDMENT, Rear Crossbar 21” WBM, RD 7101367 DUST SHIELD, 21” WBM, RD 7100820 GEAR, Pinion 7014341 RETAINING RING 7500647 ASSY, Wheel, 9” Snapper Tread w/Bearing Charcoal Gray 7100914 GEAR, External Wheel 7091196...
-
Page 14: Transmission (21")
Transmission (21") Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N... - Page 15 Transmission (21") Item Part No Description ASSY, TRANSMISSION, 21 (not sold as an assembly) 7091195 SCREW, #10-16 x 3/4” Pan Head Self-Tap, Combo 7100863 BELT GUIDE, Transmission 7100883 BELT, Traction Drive, 21” Pivot Handle 1960251 NUT, 3/8-16 Hex Center Lock Jam, Black 7100240 PULLEY, Trans Var Speed, LC WBM 7101245...
-
Page 16: Decals (21")
Decals (21") Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N... - Page 17 Decals (21") Item Part No Description 7101540 DECAL, Front Cover, 21” RD, Snapper 7102153 DECAL, Briggs Engine, Snapper 7013010 DECAL, Danger, Cut Finger 7101429 DECAL, Control Head, VS, Snapper, FC 7101536 DECAL, Control Head, VS, Snapper 7102172 DECAL, Engine, TP, 675, Snapper, FC 7101394 DECAL, Warning, Rear Discharge Door 7101671...
-
Page 18: Wiring Schematic
Wiring Schematic Manual No. 7102346 21" VARIABLE SPEED TP 400-5362-C-WB-N... - Page 19 Wiring Schematic Item Part No Description 7101504 WIRE HARNESS, Snapper, RD 21” Footnotes: 21" VARIABLE SPEED Note Manual No. 7102346 TP 400-5362-C-WB-N...
- Page 22 Parts Manual for 21" VARIABLE SPEED REAR DISCHARGE MOWERS IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs &...
