GI 275 Quick Reference Card
Power On
To power on the GI 275 without aircraft power, push and release the Inner Knob.
GI 275 Touch Buttons
Touch Buttons have a raised appearance and allow touch selection.
Cyan border or highlight indicates a button is active and ready to receive pilot input, including but not limited to
data field adjustments, sync functions, or accessing further options.
Touch Button
rounded edge and
gradient shading
Touch to select
GI 275 Data Entry
Touch the number buttons or turn the Inner Knob to adjust the keypad data field.
Turn the Inner Knob to adjust an active data field on any main page (ADI Page, CDI Page, HSI Page, etc).
190-02246-13 Rev. A
Touch
number
buttons on
Keypad or
turn Inner
Knob
Turn Inner
Knob
Cyan highlight
indicates button is
active
Turn Inner Knob
to adjust active
data fields
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Garmin GI 275
Summary of Contents for Garmin GI 275
- Page 1 GI 275 Quick Reference Card Power On To power on the GI 275 without aircraft power, push and release the Inner Knob. GI 275 Touch Buttons Touch Buttons have a raised appearance and allow touch selection. Cyan border or highlight indicates a button is active and ready to receive pilot input, including but not limited to data field adjustments, sync functions, or accessing further options.
- Page 2 GI 275 Knob Functions Outer Knob Turn Clockwise Change page to right Scroll down menu fields Move data field cursor to right Turn Counter Clockwise Change page to left Move data field cursor to left Scroll up menu fields Inner Knob...
