Quick Setup List -

Page Setup Procedure
4 Uncrating
4 Battery Charging &
Installation
5 Check Fluid Levels
6

SAFETY CHECKS

7 Torque Mower Blades
7 Burnish Electric Clutch
7 Reduce &
Check Tire Pressure
8 Lubrication
10 Mower Assembly
14 Adjustment Procedures
3/2007
Steps to Perform
o
Remove Crate & Banding.
o
Place Transmission Release Lever in PUSH position & Roll
Tractor forward off skid.
o
Charge the Battery (Note: proceed with other setup steps
while battery is charging).
o
Install Battery.
o
Check Transmission fluid level.
o
Fill & check Engine oil level.
o
Check for LOOSE HARDWARE.
o
Check all OPERATOR CONTROLS.
o
Test PARKING BRAKE.
o
Perform MOWER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
o
Check the Seat Switch connection.
o
Perform SAFETY INTERLOCK SYSTEM CHECK.
o
Torque mower blades to 45-55 ft.lbs. (61-75 Nm.
o
Burnish Electric Clutch (run for 15 seconds, repeat 10
times) .
o
Reduce & check Tire Pressure.
(Front Tires 12-15 psi, Rear tires 10-12 psi)
o
Lubricate all grease & oil points.
o
Install Mower Deck onto Tractor and Attach Belt
o
Level Mower Deck (Side-to-side & Front-to-back).
o
Gauge Wheels.
3
LT-200 Series
TP 300-4517-00-RG-N
