4 System Configuration

For initial set-up, the IP camera needs to be configured prior to using it with your network
video management system. In most cases, only network configuration will be required. Since
not all camera parameters can be controlled via networked video management systems.
The initial configuration can be done locally on the IP camera using a laptop directly
connected to the device‟s network port, or remotely over the network .

4.1 Network Configuration

By factory default, the Oculus IP is configured with an IP of 192.168.1.100. If you are not using a DHCP
and the fixed IP number has been cleared the
camera encoder it will automatically allocate itself an APIPA (Automatic Private IP Addressing) address in
the range 169.254.0.1 to 169.254.255.254 with subnet mask 255.255.0.0.
For twin-camera and encoder models the second encoder is configured with an IP of 192.168.1.101.
It is suggested to always keep the second channel IP number as on above that of the primary output.
Both the primary encoder and the secondary encoder can be configured for DHCP allocation of their IP
numbers.
Advanced device network configuration can be made via the Integrated Configuration Tool (ICT).
Contact Silent Sentinel for information on this.
