- Page 1 User Manual EPIRB1 Pro Category 1 Emergency Position Indicating Radio Beacon English www.oceansignal.com...
- Page 2 The technical data, information and illustrations contained in this manual were believed to be correct at the time of print. Ocean Signal Ltd reserve the right to change specifi cations and other information contained in this manual as part of our continual improvement process.
- Page 3 EPIRB1 Pro USER MANUAL IN CASE OF EMERGENCY USE ONLY IN SITUATIONS OF GRAVE OR IMMINENT DANGER MANUAL ACTIVATION Pull the pin Release the catch Turn the knob Release the EPIRB Remove the cover Break the tab Lift the fl ap...
-
Page 4: Table Of Contents
EPIRB1 Pro USER MANUAL GENERAL Introduction Exposure to RF Electromagnetic Energy Warnings What’s in the Box Operating Modes EPIRB1 PRO OVERVIEW INSTALLATION Location Fitting the Float Free Housing LOADING THE EPIRB1 PRO OPERATION Manual Activation Deactivation FALSE ALERTS TESTING Beacon Test... -
Page 5: General
This product complies with EN62479 (EU) and RSS-102 (Canada). Warnings It is a legal requirement to register your EPIRB1 Pro with your National Authority. Only use your EPIRB1 Pro in a situation of grave and imminent danger. Deliberately misusing your EPIRB1 Pro or setting it off accidentally may result in prosecution and a fi... -
Page 6: Operating Modes
1.5.3 Manual activation in a life raft The EPIRB1 Pro may be deployed in a life-raft, where it should be held in a vertical position so that there is a clear view of the sky, preferably outside of the canopy. -
Page 7: Epirb1 Pro Overview
Serial Number/ UIN Label Programming Details Label The lanyard is provided to attach the EPIRB1 Pro to the life raft or your person, once it is activated. Do not use it to attach it to the ship, as this may result in the loss of the EPIRB1 Pro if the vessel sinks. -
Page 8: Installation
EPIRB1 Pro for maintenance and servicing. To ensure that the EPIRB1 Pro will always fl oat free from the sinking vessel ensure that the fl oat free housing is located high up on the superstructure, free from any obstructions and located in a position that it will not be trapped, regardless of the angle the sinking vessel may be in. - Page 9 Prior to installation the EPIRB must be removed from the housing. Remove the pin Release the safety catch from the release knob Turn the knob anti-clockwise to release the cover Pull the cover free and discard. Lift the Hydrostatic clip and remove the EPIRB1 Pro from the mount 27/07/2020 912S-03403-02.00...
-
Page 10: Fitting The Float Free Housing
fi xings (not supplied). Fixing holes ‘E’ are provided to match the Ocean Signal E100/E100G if this product is being used to replace these older models. 3.2.1 Mounting Dimensions 912S-03403-02.00... - Page 11 EPIRB1 Pro USER MANUAL 3.2.2 Retro-fi t Adapter Bracket The EPIRB1 Pro Float Free Housing comes with an adapter bracket that allows easy installation where older EPIRBs from other manufacturers have been fi tted. Attach the adapter bracket to the Float Free Housing using the two holes ‘A’ and the self tapping screws provided.
-
Page 12: Loading The Epirb1 Pro
The area around the activation controls and the lanyard should be free from water and dirt to ensure reliable operation. The EPIRB1 Pro is held in place inside the Float Free Housing by the Hydrostatic Release Unit (HRU) which locks into position using a spring. - Page 13 An activation instruction label is provided and should be positioned close to the installation to assist any member of the crew or passengers in the activation procedure should they need to manually remove and activate the EPIRB1 Pro. 27/07/2020 912S-03403-02.00...
-
Page 14: Operation
GRAVE OR IMMINENT DANGER The EPIRB1 Pro is designed for best operation while fl oating in water. If used in other situa- tions ensure that the EPIRB1 Pro is placed in the open, clear of any cover and kept upright. -
Page 15: Manual Activation
5.1.1 Removing from the Enclosure Remove the pin Release the safety catch from the release knob Turn the knob anti-clockwise to release the cover Pull the cover free and discard. Lift the Hydrostatic clip and remove the EPIRB1 Pro from the mount 27/07/2020 912S-03403-02.00... - Page 16 Press and hold the red button for 1 second to activate. (Until the green LED starts to fl ash) The EPIRB1 Pro will now be operational. The strobe lights will begin to fl ash at a rate of once every 2.5 seconds as soon as the unit is activated.
-
Page 17: Deactivation
EPIRB1 Pro has been released. If the EPIRB1 Pro is mounted in the fl oat free housing in the event that the vessel sinks the EPIRB1 Pro will automatically be ejected from the housing allowing it to fl oat to the surface and begin transmission. -
Page 18: False Alerts
The EPIRB1 Pro is fi tted with water activation contacts. Although the fl oat free housing is designed to prevent accidental activation in heavy seas and adverse weather conditions, if the EPIRB1 Pro is not correctly fi tted in its housing it is possible that this may cause a false alert situation If the unit has been dropped into the water then remove from the water and dry the case, wait approximately 30 seconds for the water contacts to de-activate. -
Page 19: Beacon Test
EPIRB1 Pro is needed. To test your EPIRB1 Pro is functioning correctly, press and hold the TEST key for at least one second. The red LED will come on to indicate the switch is depressed, followed by the red LED fl... -
Page 20: Gps Test
12 tests over the lifetime of the battery, after this the GPS test will fail to activate. This test must only be performed where the EPIRB1 Pro has a clear and unobstructed view of the sky. This is required to allow the GPS receiver to acquire a signal from suffi... -
Page 21: Inspection
EPIRB1 Pro USER MANUAL Inspection During the monthly EPIRB self test it is advised that the following inspection is performed. • Inspect the EPIRB for obvious signs of damage – including the state of the antenna any creases in the antenna may cause the operation of the EPIRB to be impaired. -
Page 22: Cospas/Sarsat System
EPIRB1 Pro USER MANUAL COSPAS/SARSAT SYSTEM The COSPAS/SARSAT system utilises two satellite arrays to provide distress alert and location data to search and rescue authorities: • The GEOSAR system can provide near immediate alerting within the coverage of the receiving satellite. -
Page 23: Appendix
APPENDIX HRU Replacement The EPIRB1 Pro is mounted in a fl oat free housing, this contains a HR1E Hydrostatic Release Unit (HRU). The HRU unit must be replaced two years after installation - the expiry date is marked on the HRU and on the front of the housing. -
Page 24: Maintenance And Troubleshooting
EPIRB1 Pro on an aircraft please contact your airline for advice Disposal Care should be taken when disposing of your EPIRB1 Pro when it is no longer required. It is recommended to remove the battery from the EPIRB by removing the case lid. The case screws are covered by the top label. -
Page 25: Specifi Cations
EPIRB1 Pro USER MANUAL Specifi cations 406MHz Transmitter Frequency 406.040 MHz ±1KHz Output Power 12W EIRP Modulation Phase ±1.1 Radians Pk (16K0G1D) Encoding Biphase L Rate 400 bps 121.5MHz Transmitter Frequency 121.5 MHz Output Power 40mW±2dB Modulation Swept Tone AM (3K20A3X) -
Page 26: Approvals
Registration It is a legal requirement to register your EPIRB1 Pro with your national authority. Failure to do so may result in prosecution. Accurate registration will help the authorities if your EPIRB1 Pro is activated and may speed up your rescue. -
Page 27: 9.10 Limited Warranty
Ocean Signal will at its discretion, repair or replace faulty product free of charge excluding the cost of shipping. Proof of purchase shall be required in order for a warranty claim to be valid from the original purchaser. All claims shall be made in writing to Ocean Signal or an approved service dealer. - Page 28 Ocean Signal Ltd. Unit 4, Ocivan Way Margate CT9 4NN United Kingdom info@oceansignal.com www.oceansignal.com...
