AMX NI-2000 Dimension Manual

17.0
431.8
LINK/ACT INPUT 1 2 3
1 2 3 4
TX RX TX RX TX RX
STATUS OUTPUT RS - 232 / 422 / 485 RELAYS
19.0
482.6
PORT 3 PORT 2 PORT 1
RS - 232 / 422 / 485
RELAYS (Port 4) I / O (Port 9) IR / SERIAL (Ports 5-8)
4 3 2 1 4 3 2 1 PROGRAM CONFIGURATION
B A B A B A B A 4 3 2 1
1 2 3 4 1 2 3 4
IR / SERIAL I / O
ICSNet ICSNet ICSHub Out
RS - 232 / 422 / 485
(Ports 1-3)
ETHERNET
Pin Function Pin Function 10 / 100 AXLink PWR
L/A SPD
1 RX- 6 RX+
12VDC
RXD
2 7 RTS
3 TXD 8 CTS
ID
4 TX+ 9 TX-
5 GND
NOTICE: This drawing is the
property of AMX Corporation.
All information contained herein
that is not generally known
shall be confidential except
to the extent the information
has been previously established.
This drawing may not be copied,
reproduced, or used as the basis
for manufacture or sale without
written permission.
REV ECN
A 4735
3.5
3.59
88.1
[91.1]
3.5
88.1
REL APPR
UNLESS OTHERWISE SPECIFIED:
DAS
DRAWN
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
LC
XXX = .005 ENGR SERV
TOLERANCE ON HOLE DIAMETERS:
PL
ENGINEER
UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
KZ
PROD ENGR
OVER .500 = +.008 -.005
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
JM
MATL SUP
ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH. AK
QUALITY
ALL DIMENSIONS IN INCHES.
THIRD ANGLE
DO NOT SCALE THIS DRAWING.
PROJECTION
REVISIONS
DESCRIPTION DATE APPR
RELEASE FOR PRODUCTION 2/18/03
REL DATE REV APPR
AMX CORPORATION
2/4/03
2/18/03
PICTORIAL,
2/18/03
NETLINX INTEGRATED CONTROLLER
2/18/03
NI-2000
2/18/03
2/18/03
SIZE DWG. NO.
SCALE: 1:2
C
95-2105-01
95-2105-01-A
SHEET 1 OF 1
-
REV.
A
