1. PRODUCT OVERVIEW

1.1. General Description

The Protoss-PE11 provides a RS485 interface to TCP/IP data transfer product. The Protoss-PE11
integrate TCP/IP controller, memory, 10/100M Ethernet transceiver, RS485 and integrates a fully
developed TCP/IP network stack and FreeRTOS OS. Protoss-PE11 also includes an embedded web
server used to configure device.
The Protoss-PE11 using highly integrated hardware and software platform, it has been optimized for
all kinds of applications in the industrial control, smart grid, personal medical application and remote
control that have lower data rates, and transmit or receive data on an infrequent basis.

1.2. Device Paremeters

Item
System Information
Processor/Frequency
Flash/SDRAM
Operating System
Ethernet Port
Port Number
Interface Standard
Transformer
Network Protocol
Security Protocol
Serial Port
Port Number
Data Bits
Stop Bit
Check Bit
Baud Rate
Flow Control
Software
Web Pages
Configuration
http://www.hi-flying.com
Table1. Protoss-PE11 Technical Specifications
Parameters
Cortex-M3/96MHz
2MB/128KB
FreeRTOS
1
10/100 Base-T Auto-Negotiation
Integrated
IP，TCP，UDP，DHCP，DNS，HTTP Server/Client，ARP,
AutoIP, ICMP， Telnet, NTP, Modbus TCP
AES 128Bit
DES3
1 RS485
5,6,7,8
1,2
None, Even, Odd
TTL: 600 bps~460800 bps
No Flow Control
Software Xon/ Xoff flow control
Http Web Configuration
Customization of HTTP Web Pages
Web
CLI
XML import
