MOTOR INTAKE FILTER

Prevents various particles (from carpets, dust or dirt present in the air)
from reaching the motor and filters the motor cooling air.
1. Check that the motor intake filter is clean at least once a month.
2. If needed, remove and rinse the motor intake filter frequently. To remove
it, first remove the tank. Find the lower cover and remove it by undoing the
central screw, using your hands or a coin. Remove the filter (Pict. 5-6-7) and
wash it with water.
Before using the vacuum cleaner again, make sure the filters are dry, so that
they can operate at their best.
Do not leave the motor intake filter to dry on heaters or radiators!
5
UPPER LID FILTER
Check the Upper Lid Filter when you clean the
purification tank. If necessary, remove and rinse the
filter. To check the Upper Lid Filter:
1. Loosen the knob on the cover by turning
countericlockwise (Pict.8).
2. Remove the cover from the lid, grabbing it with
your hands (Pict.9).
3. Remove the filter.
4. Wash the filter with cold water.
Do not leave the sponge filter to dry on heaters or
radiators! Replace the filter if it has stains that you
cannot remove.
FILTER REPLACEMENT:
Air Intake Filter: Replace yearly or earlier according to condition.
Polyester Filter: Replace yearly or earlier according to condition.
Motor Intake Filter: Replace yearly or earlier according to condition.
Low Noise Filter: Replace yearly or earlier according to condition.
Upper Lid Filter: Replace yearly or earlier according to condition.
EN
8.2 CARICO'S RSS
After each use, clean the purification tank which is all that is required for
maintaining CARICO'S COMPLETE SANITIZING SYSTEM efficiency. When you
are done cleaning, empty the liquid waste of the purification tank as shown in
Pict. 10 and rinse thoroughly.
The CARICO COMPLETE SANITIZING SYSTEM has two nebulizers (Pict. 12). The
nebulizers include silver rings which inhibit the growth of bacteria and odors
in the tank.
To make this operation easier, remove the divider inside the tank (Pict. 11).
Remove the nebulizers (Pict. 12). Rinse tank, divider and nebulizers with hot
water until all residues and stains on the tank walls are removed.
6 7
When you take off the divider, make sure to put it back correctly into the proper
guides with its curved side facing forwards and upwards and that it touches the
8
bottom (otherwise it won't slide in). Please be careful, these are delicate pieces.
If one gets broken or lost, immediately obtain a spare part from an authorized
Carico Service Center. Do not use the CARICO'S COMPLETE SANITIZING SYSTEM
without it. Allow all pieces to dry or dry them yourself before replacing them in
the machine and closing the cover. Moisture left inside could create mildew and
unpleasant odors.
TIP: Here is an easy way to clean your attachments:
9
Empty the tank and vacuum 1 liter of clean tap water through the accessories
you used, repeat as needed.
TM
10
CAUTION!
11 12
