Air Intake Filter; Polyester Filter - Carico ULTRA TECH CLEAN MACHINE Manual

After intense use (or at least once every six (6) months) check all filtering
elements. Clean the appliance's outer surfaces with a cloth. Should the
appliance fall or overturn, switch off immediately and disconnect from the
power. If the machine comes in contact with water, dry it with a dry cloth and
wait a few minutes before switching on again. Do not put away the appliance
while the tank still contains dirty water, which may cause bad smells from mold
and encrustations forming inside the tank.
Do not direct jets of water or high pressure steam at the appliance to
clean it! (even when disconnected from the power)
IMPORTANT! Before carrying out any type of maintenance, turn the
machine off and disconnect from the power.
8.1 FILTERS
Immediately replace any filter if you notice any damage to them! Contact
your authorized Carico Service Center for new filters.
CAUTION! Do not use the appliance until all filters are perfectly dry.
Using a damp filter could damage the appliance. If stains or mold appear
on the filters, replace them with new ones from an authorized Carico Service
Center. The life of this filter is strongly influenced by how much the appliance
is actually used.

AIR INTAKE FILTER

The air intake filter keeps particles from reaching the motor. Check the
efficiency of filter when you are cleaning the purification tank.
To do this, remove and rinse the filter
repeatedly, separating it from the cover
and the machine body (Pict.1). Use small
pliers (eyebrow tweezers will do). Wash
the filter element with plenty of cold
water. Do not leave the filter to dry on
heaters or radiators!
If stains or mold appear on the filter
EN
8 - MAINTENANCE
surface, replace them with new ones, from an authorized Carico Service Center.
The life of this particular component is strongly influenced by how much the
appliance is actually being used.

POLYESTER FILTER

To keep the filter clean and ready for maximum performance, inspect it
monthly.
To inspect the filter:
1) Remove the exhuast filter cover, at the back of the CARICO COMPLETE
SANITIZING SYSTEM B (Pict. 2). The polyester filter is fitted inside. Lay the
exhaust filter cover, on the floor and extract the filter as shown (Pict. 3).
2) Check the filter; if there are traces of dust or dirt, wash with plenty of warm
water to remove.
3) Allow the filter to dry naturally (not on radiators or heaters).
Do not use the appliance until the filter is perfectly dry. Use of a damp
filter could damage the appliance.
4) After cleaning, put the filter back into place and reassemble the cover,
making sure to properly fit the exhuast filter cover hooks
onto the slits on the appliance body. Once the filter cover is in place,
rotate it upwards for the final fixing with the stopping tongue.
Replace the polyester filter if torn or damaged.
1
2 3
19
