Instruction Manual
Genius Compact Stroller
The illustrations shown in this manual are for reference only. The manufacturer reserves the right to change any specification
or feature without further notice.
IMPORTANT!
PLEASE READ CAREFULLY &
KEEP FOR FUTURE REFERENCE
This product is designed to comply with Australian and New Zealand standard
AS/NZS2088:2013.
0-36
15
months
kg
MAXIMUM
WEIGHT
OF CHILD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Genius Compact Stroller and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for anko Genius Compact Stroller

Summary of Contents for anko Genius Compact Stroller

  • Page 1 Instruction Manual 0-36 Genius Compact Stroller months MAXIMUM WEIGHT OF CHILD The illustrations shown in this manual are for reference only. The manufacturer reserves the right to change any specification or feature without further notice. IMPORTANT! PLEASE READ CAREFULLY &...
  • Page 2 WARNING RETAIN FOR FUTURE REFERENCE. READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND USE OF THIS PRAM/STROLLER. ALWAYS FOLLOW THE INSTRUCTIONS. THE CORRECT USE AND MAINTENANCE OF THIS PRODUCT IS ESSENTIAL. WARNING TO AVOID INJURY OR DEATH: ALWAYS APPLY THE BRAKES WHENEVER THE PRAM/STROLLER IS STATIONARY.
  • Page 3 WARNING THE PRAM/STROLLER IS DESIGNED FOR USE ON FLAT OR GENTLY SLOPING SURFACES AND CAN BECOME UNSTABLE ON HIGHER SLOPING OR UNEVEN SURFACES. USERS SHOULD BE AWARE OF THE POSSIBILITY OF THE STROLLER ROLLING AWAY OR TIPPING OVER. • WITH YOUR HAND THROUGH THE WRIST TETHER STRAP LOOP, PUSH THE PRAM/STROLLER HOLDING BOTH HANDLES.

  • Page 4: Manual Handling Techniques

    WARNING MANUAL HANDLING TECHNIQUES The SMART lifting technique; This technique can be used to pick up small light loads from low levels. Size up the Load; • Assess the load (size, shape and weight). • Assess whether the load needs to be moved. •...
  • Page 5 Stroller Components Fold Handle Canopy Handle Bumper Bar Seat Safety Buckle Adjust Button Footrest Brake Pedal Rear Wheel Swivel Lock Basket Front Wheel Frame Bumper Bar Front Wheel x2 Rear Wheel(L) x1 Rear Wheel(R) x1...
  • Page 6 Assembly of Stroller 1. To Open Stroller (1) Open storage latch (Fig. A). (2) Lift handle of stroller up (Fig. B & C). (3) Place foot on the Grey Lock Pedal then lift handle of stroller up until a ‘click’ is heard (Fig. D). CHECK that the stroller is completely latched open every time you open the stroller and before...

  • Page 7: Front Wheels

    2. Front Wheels (4) Slide each front wheel assembly onto the mounting post at the front of the stroller (Fig. A). A ‘click’ will be heard. Pull wheel to CHECK and ensure that it is secure. To release wheel for easy transport or storage, push the wheel release tab on the inside of the stroller frame and pull the wheel away from the stroller (Fig.

  • Page 8: Using The Brakes

    4. To Use Bumper Bar (6) Opening / closing the Bumper Bar: Press the bumper into the slots to install. It will click into place (Fig. A). Press the buttons on two sides of the arm together to release the bumper bar (Fig. B). WARNING: WHEN A CHILD IS IN THE STROLLER, KEEP THE ARM BAR...

  • Page 9: Swivel Wheel

    6. Swivel Wheel (8) Push the swivel lock switch fully down to lock the front wheel. Press the swivel lock switch fully up to allow the wheel to swivel (Fig. A). 7. Footrest (9) To raise: Hold the footrest front and raise it to up position (Fig.

  • Page 10: Adjusting The Backrest

    8. Adjusting The Backrest (10) For upright sitting position: Pull the webbing on both sides outwards to adjust the backrest upright (Fig. A). For reclined laying position: Pull the buckle downwards for the backrest to recline into laying position (Fig. B). WARNINGS: •...
  • Page 11 9. Securing Your Child In Harness WARNING: USE THE HARNESS AT ALL TIMES. When not in use, disconnect straps from the buckle to prevent strangulation. A five point harness is provided to restrain your child. Buckle tongues are separate for added safety. To reconnect buckle tongues and secure the child in the harness carefully, follow the steps below.
  • Page 12 9. Securing Your Child In Harness (14) To tighten or loosen the shoulder strap: Hold and lift the slider and then pull the harness strap to adjust to the desired fit. The shoulder straps need to fit firmly around the child (Fig D). Tighten loosen (15) For a bigger child, push the shoulder harness...

  • Page 13: To Fold The Stroller

    10. To Fold The Stroller (17) On the handlebar, squeeze the Side Lock button (1) and then press the Fold Button (2) to enable the handle bar to fold downward (Fig. A & B). (18) Fold the handlebar downward until it meets the frame (Fig. C). (19) Hold the handle and frame together on each side and fold forward towards the seat.
  • Page 14 10. To Fold The Stroller (20) The Folding Handle is under the seat. Pull up on the “Pull to Fold” folding handle and let the frame collapse. (Fig. E). (21) Make sure the auto-lock storage latch clicks into place. Stroller can stand up after folding (Fig.

  • Page 15: Tether Strap

    12. Tether Strap A wrist tether strap is provided on the handle grip. Slide your hand through the tether strap loop whenever you use the pram/stroller. Only remove your hand from the tether strap loop when the brakes have been applied to the pram/stroller wheels. CARE AND MAINTENANCE •...
