ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3187PC-2PK
DIFFICULT
Page 1 of 5
Tools Required for Assembly:
Allen Wrench
Phillips Screwdriver
Wrench
(Included)
(Not Included)
(Not Included)
Rev.14-11-21
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3187PC-2PK
Summary of Contents for Furniture of America CM3187PC-2PK
- Page 1 Assembly Instructions CM3187PC-2PK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc x 2 #A x 4 pcs x 2 Backrest w/Legs Bolt 1/4”x3-1/4”...
- Page 4 Place the backrest with legs (#1) on a protected surface. Align the seat (#2) with the pre-drilled holes of the backrest with legs (#1). III. Prepare 3 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
- Page 5 #C x 4 pcs #D x 4 pcs #E x 4 pcs Insert the front leg support (#4) between the 2 front legs (#3). Then insert the 2 side leg supports (#5) into the backrest with legs (#1) and the 2 front legs (#3). II.
