ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3187PBN
DIFFICULT
Page 1 of 5
Tools Required for Assembly:
Allen Wrench
Phillips Screwdriver
Wrench
2 PERSONS RECOMMENDED
(Included)
(Not Included)
(Not Included)
Rev.14-11-21
Advertisement
Related Manuals for Furniture of America Dickinson CM3187PBN
Summary of Contents for Furniture of America Dickinson CM3187PBN
- Page 1 Assembly Instructions CM3187PBN ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Phillips Screwdriver easy and 5 being difficult). For some (Not Included) products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 4 pcs Backrest w/Legs Bolt 1/4”x3-1/4” #B x 3 pcs #2 x 1 pc Bolt 1/4”x1-1/2”...
- Page 4 Place the backrest with legs (#1) on a protected surface. Align the seat (#2) with the pre-drilled holes of the backrest with legs (#1). III. Prepare 3 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
- Page 5 #C x 4 pcs #D x 4 pcs #E x 4 pcs Insert the front leg support (#4) between the 2 front legs Turn right (clockwise) to tighten (#3). Then insert the 2 side leg supports (#5) into the backrest with legs (#1) and the 2 front legs (#3).
