Phocos CXup Series Faq

Load settings pwm charge controller
Hide thumbs

Advertisement

Table of Contents

FAQ: CXup Load Settings
1.0
Buttons ........................................................................................................................................................................................... 1
2.0
Enter Settings Menu .............................................................................................................................................................. 2
3.0
Dusk to Dawn (D2D) .............................................................................................................................................................. 3
4.0
Load on for 30 Minutes After Dusk ............................................................................................................................... 4
1.1

Buttons

1. ESC
2. DOWN
3. UP
4. SET
Phocos Americas Inc.
Contents
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CXup Series and is the answer not in the manual?

Questions and answers

Related Manuals for Phocos CXup Series

Summary of Contents for Phocos CXup Series

  • Page 1 FAQ: CXup Load Settings Contents Buttons ......................................1 Enter Settings Menu ................................2 Dusk to Dawn (D2D) ................................3 Load on for 30 Minutes After Dusk ..........................4 Buttons 1. ESC 2. DOWN 3. UP 4. SET Phocos Americas Inc. Page 1...
  • Page 2 Press ESC to enter the main menu. Use the UP or DOWN arrow key to navigate between datalogging (LOG) and settings (Set) menus. When the LCD shows Set, select the settings menu by pressing the SET button. Use the UP or DOWN arrow key to navigate the settings submenus. Phocos Americas Inc. Page 2...
  • Page 3 When the LCD shows the D2D setting, press SET to save the setting. The D2D setting will flash briefly to confirm the selection. The LCD should automatically display NL again. Press ESC exit the settings menu. Press ESC again to return to the status display. Phocos Americas Inc. Page 3...
  • Page 4 Use the UP or DOWN arrow key to navigate the nightlight submenu. The previously selected setting will flash. When the LCD shows the DD setting, press SET to save the setting. The DD setting will flash briefly to confirm the selection. The LCD should automatically display NL again. Phocos Americas Inc. Page 4...
  • Page 5 When the LCD shows the 0.5 setting, press SET to save the setting. The 0.5 setting will flash briefly to confirm the selection. The LCD should automatically display Eve again. Use the UP or DOWN arrow key until the LCD shows the morning submenu (Mor). Press SET to enter the morning submenu. Phocos Americas Inc. Page 5...
  • Page 6 When the LCD shows the 0.0 setting, press SET to save the setting. The 0.0 setting will flash briefly to confirm the selection. The LCD should automatically display Mor again. Press ESC exit the settings menu. Press ESC again to return to the status display. Phocos Americas Inc. Page 6...
  • Page 7 FAQ: CXup Load Settings Document Version Date Revision Description Author 2018-01-18 Initial version with D2D, 0.5 hr after dusk Megan Cornman Phocos Americas Inc. Page 7...
