2.3 FLIP TIP2 LOCK

The front nozzle is locked in both positions. To change positions follow the steps in fi gure 2.3.
CAUTION
NOTICE
2.4 REAR SMOOTH BORE INSERTS
The rear smooth bore inserts may be removed by removing the retaining ring and pulling the insert out the front of the nozzle.
2.5 FRONT SMOOTH BORE NOZZLE
©Copyright Task Force Tips, Inc. 2014
1
Unlock
2
Figure 2.3 Using the Flip Tip2 Lock
Do not pivot the Flip Tip between positions while fl owing water. High velocity water can be
discharged in harmful directions. Always turn off water before changing positions.
When the front nozzle is in the down position the sealing surfaces are exposed. Avoid actions
which can damage the sealing surface to prevent possible leakage and repairs.
Figure 2.4 Rear Smooth Bore Inserts
Figure 2.5 Front Smooth Bore Nozzles
Flip Down
2.0" diameter if no insert is installed
Smooth Bore Insert
1.0", 1 1/4", 1 3/8" or 1 1/2"
O-Ring
Male Hose Thread for attaching a hose
or other nozzle of proper thread
Smooth Bore Nozzle
5
1
Unlock
Flip Up
2
Retaining Ring
(use a pick or similar
tool to remove)
LIN-065 February 11, 2014 Rev00
