Triton INSTAFLOW Installation And Operating Instructions Manual

5/10/15 litre unvented stored water heater
Hide thumbs Also See for INSTAFLOW:

Advertisement

Quick Links

I N STAFLOW
Unvented Stored
W a t e r H e a t e r
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The water heater installation MUST be carried out by a suitably qualified person, in the sequence of
this instruction book.
t a n k c a p a c i t i e s
IMPORTANT SAFETY ADVICE
During installation of the water heater the
supplied pressure reducing valve must be
fitted.
Failure to use genuine Triton parts may cause
injury and invalidate your guarantee.
2181622C - February 2020
Power
Heating
A v a i l a b l e i n 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the INSTAFLOW and is the answer not in the manual?

Questions and answers

Related Manuals for Triton INSTAFLOW

Summary of Contents for Triton INSTAFLOW

  • Page 1 NOTE DOWN THE PRODUCT CODE BELOW supplied pressure reducing valve must be (FROM THE FRONT OR TOP OF THE BOX) fitted. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321 INSTALLATION AND OPERATING INSTRUCTIONS Please read this book thoroughly and familiarise yourself with all instructions before commencing installation and keep it for future reference.
  • Page 2 PLEASE READ THIS IMPORTANT SAFETY INFORMATION AND GUIDANCE NOTES Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. This book contains all the necessary fitting and operating instructions for your water heater.
  • Page 3 UNVENTED STORED WATER HEATER USER SAFETY This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 4: Technical Specifications

    UNVENTED STORED WATER HEATER TECHNICAL SPECIFICATIONS 5 litre 10 litre 15 litre ELECTRICAL Nominal power - rating at 1.5kW - 1.65kW 2.0kW - 2.2kW 2.0kW - 2.2kW 230V - 240V PLUMBING Supply source Mains pressure cold water only Minimum operating 50 kPa (0.5 bar) pressure Flow to the inlet of the...
  • Page 5 PRESSURE RELIEF VALVE (83317580) The pressure relief valve (PRV) supplied with this water heater MUST be fitted. This is a safety critical item and only the Triton 6 bar pressure relief valve (83317580) should be fitted. Details of product installation can be found from page 10 to 13 inclusive.
  • Page 6 UNVENTED STORED WATER HEATER PRODUCT DESCRIPTION This product consists of a body, plastic control panel and safety pressure relief valve. DRAINING PROCESS If it becomes necessary to drain the product, follow the procedure below. 1. Cut off the power supply. 2.

  • Page 7: Table Of Contents

    UNVENTED STORED WATER HEATER CONTENTS PAGE IMPORTANT SAFETY INFORMATION & GENERAL GUIDANCE NOTES (please read)...............2 - 5 TECHNICAL SPECIFICATIONS................7 DIMENSIONS ....................8 - 9 SITE OF THE WATER HEATER ..............10 - 11 INSTALLATION ....................12 LEAK TESTING ....................13 COMMISSIONING .................... 13 OPERATING THE WATER HEATER ..............

  • Page 8: Dimensions

    UNVENTED STORED WATER HEATER DIMENSIONS 5 LITRE 1.5mm 269.7 1.5mm 1.5mm 80.7 1.5mm G1/2 10 LITRE 1.8mm 299.9 1.5mm 93.2 1.5mm G1/2...
  • Page 9 Before beginning the installation please check the contents to make sure all parts are present. 1. Installation and operating instructions 2. Instaflow water heater 3. Wall bracket 4. 1.2m cable fitted with UK plug 5. Screws and wall plugs (suitable for brick wall) 6.

  • Page 10: Installation

    The diagrams on page 11 (fig.2 and fig.3) show the plumbing requirements, where expansion cannot be accommodated within the pipework the appropriate accessory kits must be procured. Triton recommends the use of copper pipe, the use of other materials is beyond the scope of this installer guide.
  • Page 11 UNVENTED STORED WATER HEATER Fig.2 Typical installation with expansion allowed in the incoming pipework Nearest cold water 6 bar pressure draw off relief valve Dielectric Cold junctions Isolating valve supply supply Discharge Expansion distance required for 15mm pipes, this can be approximately halved for 22mm pipes.
  • Page 12 UNVENTED STORED WATER HEATER FIT THE BRACKET TO THE WALL Fig.4 Using the bracket as a template, mark the fixing holes on the wall, ensuring the bracket is level. Drill and plug the wall. An appropriate drill but should be used. Note: If the wall is plasterboard or a soft building brick please select an appropriate wall fixing method;...

  • Page 13: Leak Testing

    UNVENTED STORED WATER HEATER LEAK TESTING Flush out the pipework to remove any debris. Open the water isolating valves and check for leaks. Rectify any leaks found before proceeding with commissioning. COMMISSIONING Important: This procedure must be completed with the electricity switched OFF at the isolating switch.

  • Page 14: Operating The Water Heater

    The thermal cut-out switches off the power supply should the water temperature reach excessive values. If this device is activated, you should call our Triton Customer Experience helpline. Pressure will increase when the temperature increases by releasing the excess pressure through the drain outlet.

  • Page 15: Maintenance

    Triton recommend an annual inspection to keep your water heater working correctly - this inspection must be carried out by a suitably competent person. Replacement parts are available from Triton Customer Experience - see contact details on page 17.
  • Page 16 UNVENTED STORED WATER HEATER IMPORTANT: Switch off the electricity supply and remove the circuit fuse before attempting any fault finding inside the unit. All repairs/corrective actions should be carried out by a suitably qualified person. PROBLEM POSSIBLE CAUSE ACTION Pressure relief valve Mains pressure is above 6 bar.
  • Page 17 Please have your model name available. WEEE Directive – Policy Statement As a producer and a supplier of electric showers, Triton Showers is committed to the protection of the environment via our own environmental policy and compliance with the WEEE directive.
  • Page 18 UNVENTED STORED WATER HEATER...
  • Page 19 UNVENTED STORED WATER HEATER...
  • Page 20 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited E-mail: technical@tritonshowers.co.uk Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2020...
