- Page 1 MSUB12-I DP5300/Rev01 - DI Installation kit for MSUB12-I Contents: - Read t his docum ent before using. - Keep t his docum ent . - Observe all warnings and caut ions. PAGE 1 OF 4...
- Page 2 Rigging Place MSUB12 on the top of a second MSUB18. Insert 4 pins (2 on both sides). Secure with the provided plats and the screws. How to connect a second cable? Remove the driver. Wire the provided connector WAGO 4pt. Plug it to the free connector.
- Page 3 Setting MSUB12-I is packaged with the connection plate on the back. You can place a connection plate on the front. Remove the connection plate with the cable glands. Place the Remove the cable glands. provided plate. Place the front plate on the grille. Pass the cable before closing Assemble the cable glands on the front plate the front grille.
- Page 4 • NEXO cannot accept responsibility for accidents caused by any factor other than defects in this product itself. • Please check the web site nexo-sa.com for the latest update. - Read t his docum ent before using. - Keep t his docum ent .
