To Invert The Camera Image; To Remove The Distance Guide Lines - Boss Audio Systems ELITE ELPC40B User Manual

OPTIONAL

To remove the distance guide lines:

1. Turn the system OFF before proceeding
2. Cut the white loop wire located at the connection points
(camera end).
3. Insulate the wire, using tape or crimp connectors on both ends.
4. Reconnecting the wire will display the guide lines again.

To invert the camera image:

1. Turn the system OFF before proceeding
2. Cut the blue loop wire located at the connection points (camera end)
3. Insulate the wire, using tape or crimp connectors on both ends.
4. Reconnecting the wire will orient the image back to its original position.
