- Page 1 Installation Manual for Outdoor Unit AV08NMSETA AV10NMSETA AV12NMSETA No. 0150512770 • Please read this manual carefully before using • Keep this operation manual for future reference...
-
Page 2: Table Of Contents
User Manual CONTENT Safety ............1 MRV -S adopts "simultaneous control" type, all indoors should be heating or Installation instruction ........3 cooling simultaneously. Installation procedure ........6 To protect compressor, before startup, the Electric wiring and the application ..... 21 unit should be electrifi... -
Page 3: Safety
Safety • This manual should always be accessible and close to this air condition equipment. • There are two types of indications, " WARNING" and " CAUTION". The indication preventing from death or heavy injury is listed as " WARNING". Even the indication listed as "... - Page 4 Safety CAUTION • Grounding wire should be connected with the grounding bar. The grounding wire can not be connected to the gas pipe, water pipe, lightening rod or the telephone grounding wire. Improper grounding may cause electric shock. • Units installed on roof should have appropriate access and handrail. •...
-
Page 5: Installation Instruction
Installation instruction For installation, please review the items below: • Is the connected units quantity and the total capacity in the allowable range? • Is the refrigerant pipe length in the limited range? • Is the pipe size proper? And if the pipe installed horizontally? •... - Page 6 Installation instruction (2) Installation place selection Air-conditioner can't be The unit should be installed The unit should be installed at installed in the place with at the place with good the strong enough place. Or it will infl ammable gas. Or it will ventilation.
- Page 7 Installation instruction (3) Transportation and hoisting Hoisting • Please remove the outdoor unit to the installation location as far as possible near place befor open the packaging. • Forbid on the equipments to place anything, need to use 2 ropes while promoting outdoor. •...
-
Page 8: Installation Procedure
Installation procedure Outdoor Installation Installation location • Outdoor unit should be placed in well ventilated and dry place. • Outdoor noise and exhaust should not affect neighbors and around the ventilation. • Ensure the ground steadily reliable. • Do not install the outdoor unit on high oil,salt spray or harmful gases. •... - Page 9 Installation procedure Multi Outdoor Min300mm Inlet Outlet Min300mm...
- Page 10 Installation procedure Case 2: stumbling block on the inlet and top side Single Outdoor Max300mm Max300mm Min360mm Min360mm Multi Outdoor...
- Page 11 Installation procedure Not more than two sets Case 3:stumbling block on the outlet, both right and left side Single Outdoor Min360mm Min1000mm Min300mm Min150mm...
- Page 12 Installation procedure Multi Outdoor If h>H, please set the outdoor on the foundation to make sure H≥h. H=The height of outdoor and foundation 0<h≤1/2H Over 600 1/2H<h≤H Over 1400 Note: Avoid making air short cycle in any case.
- Page 13 Installation procedure Multi Row Outdoor Note: Make sure the distance at least 300mm between two neighbor units and no stumbling block. 0<h≤1/2H Over 600 1/2H<h≤H Over 1400...
- Page 14 R410A, if the pipe over 19.05 is 0-type, the pressure preservation will be bad, thus it must be 1/2H type and over the min. thickness. 3. The branch pipe and the gather pipe must be from Haier. 4. When installing the stop valve, refer to the relative operation instruction.
- Page 15 Installation procedure Anti-fouling measures First, clean the pipe. Position Installation period Measures More than 1 month Flat the pipe end Outdoor Less than 1 month Flat the pipe end or seal with adhesive tape Indoor Nothing to do with period Pipe specifi...
- Page 16 Installation procedure 3. Pipe "c" diameter (main pipe, between outdoor gather pipe and the fi rst branch pipe) Main pipe Enlarged main pipe Outdoor capacity (kW) Gas pipe (mm) Liquid pipe (mm) Gas pipe (mm) Liquid pipe (mm) 22.4 Ø22.22 Ø9.52 Ø22.22 Ø12.7...
- Page 17 Installation procedure B. Indoor unit Gas pipe side Liquid pipe side Model Capacity Connecting Connecting Diameter (mm) Diameter (mm) method method Ø9.52 Ø6.35 Ø9.52 Ø6.35 Ø12.7 Ø6.35 Ø12.7 Ø6.35 Ø12.7 Ø6.35 Ø15.88 Ø9.52 Braze Flared Ø15.88 Ø9.52 Ø15.88 Ø9.52 Ø15.88 Ø9.52 Ø15.88 Ø9.52...
- Page 18 Installation procedure Adhesive side Seal the connection and wrap the heat insulator with adhesive tape Prepare on fi eld Cut off pipe with the cutter Horizontal Floor Cut off at the middle Floor Right Wrong Pipe installation When doing the piping connection, please do the following: •...
- Page 19 Installation procedure Operation procedure • Brazing the pipe at the same time charge the nitrogen. Or it will cause a number of impurity (a fi lm of oxidation) to clog the capillary and the expansion valve, further cause the deadly failure. Seal the pipe end with adhesive tape or the stopper to increase the resistance, fi...
- Page 20 Installation procedure B. Leakage test 1. The outdoor unit has been executed the leakage test in the factory. The pipe should be executed leakage test individually and forbidden to test after connecting with stop valve. 2. Refer to the below fi gure to charge the nitrogen into the unit to take a test. Never use the chlorin, oxygen, fl...
- Page 21 Installation procedure Because the unit is with refrigerant R410A, the below issues should be paid attention: • To prevent the different oil into the pipe, please use the special tool for R410A, especially for gauge manifold and charging hose. • To prevent the compressor oil into the refrigerant cycle, please use the anti-counter-fl ow adapter.
- Page 22 Installation procedure L1: Total length of 22.22 liquid pipe; L2: Total length of 19.05 liquid pipe; L3: Total length of 15.88 liquid pipe; L4: Total length of 12.7 liquid pipe; L5: Total length of 9.52 liquid pipe; L6: Total length of 6.35 liquid pipe; Total refrigerant volume charging on site during installation=W2+W3 W: Total refrigerant volume charging on site for maintenance.
-
Page 23: Electric Wiring And The Application
Electric wiring and the application Communication wiring fi gure The outdoor and all indoor units are in parallel through 2 non-polar wires. Three wiring methods between wired controller and indoor unit: A. 1 to multi (group control): one wired controller controls 2~16 indoors, as shown in above figure, indoor 1~indoor 5: indoor 5 is wired control master unit, the others are wired control slave units. - Page 24 Electric wiring and the application Power wiring fi gure Please make sure that when the unit is running, the input voltage is no less than 380V; if it is lower than 380V,the unit may run abnormal. power source: 3N~, 380-400V, 50/60Hz power source: 3N~, 380-400V, 50/60Hz power source: 3N~, 380-400V, 50/60Hz power source: 3N~, 380-400V, 50/60Hz...
- Page 25 Electric wiring and the application Indoor power source and communication wiring Communication wire Rated Rated current of residual Item Power Wire current of circuit breaker(A) section Indoor cable length overcurrent Ground fault Outdoor/ Indoor/ total section breaker interruptor(mA) indoor indoor current (A) response time(S) <13...
- Page 26 Electric wiring and the application Selection switch and the display In the following table, 1 is ON, 0 is OFF. Dip switch defi nition: BM1 is usually set by the personnel on site; BM2 is usually used in the factory. BM1 introduction Begin to search indoor Indoor searching...
-
Page 27: Failure Code
Failure code Failure code Inverter outdoor unit failure code Digital tube Indication indication on wired Failure code Failure description Remarks on master controller defi nition unit (hex) Defrosting AD value is below 11(open circuit) or 20-0 temp.sensor over 1012(short circuit) for 60seconds, in TE1 failure cooling mode, if the sensor is abnormal, Resumable... - Page 28 Failure code Indication indication on wired Failure code Failure description Remarks on master controller defi nition unit (hex) AD value is below 11(open circuit) or Low pressure over 1012(short circuit) for 30seconds, sensor Ps Resumable in defrosting and within 3 minutes after failure defrosting, no alarm High pressure...
- Page 29 Failure code Indication indication on wired Failure code Failure description Remarks on master controller defi nition unit (hex) In normal operation, compression ratio Compression <1.8 for continuous 5 minutes stop and Once 39-2 39-2 ratio too low alarm.2 minutes and 1 seconds later, confi...
- Page 30 Failure code Indication indication on wired Failure code Failure description Remarks on master controller defi nition unit (hex) IPM modular over current, in short circuit, IPM modular over heat, voltage too low of control protection (F0) circuit. In the course of compressor startup or Compressor out running, the unit can not detect the rotor of control...
- Page 31 Failure code When there is no failure, if the starting condition can not be met, digital tube on master unit will display stand-by code: Standby state of capacity over- When capacity is over 130% or low- match er than 50%, the system is standby. Outdoor ambient temperature too 555.1 Ta>27℃...
-
Page 32: Trial Operation And The Performance
Trial operation and the performance 5-minute delay function • If starting up the unit after being powered off, the compressor will run about 5 minutes later against being damaged. Cooling/heating operation • Indoor units can be controlled individually, but cannot run in cool and heat mode at the same time. - Page 33 Trial operation and the performance Heating capacity • The heating mode adopts the heat pump type that absorbs outdoor heat energy and releases into indoor. So if outdoor temperature goes down, the heating capacity will decrease. Trial operation • Before trial operation: Before being energized, measure the resistor between power terminal block (live wire and neutral wire) and the grounded point with a multimeter, and check if it is over 1M * .
