  • Page 1 V1.1 PowerDepot H5 User Manual...

  • Page 2: Table Of Contents

    PowerDepot H5 series User Manual Content Statement of Law ....................II Safety Precautions ....................III Preface ........................ IV 1 Introduction ....................1 1.1 Brief Introduction ....................1 1.2 Product Properties ....................1 1.3 Product identity definition ................... 2 2 Product Specification ..................3 2.1 Size and Weight....................

  • Page 3: Statement Of Law

    PowerDepot H5 series User Manual 4.3 Analysis and treatment of common faults ............27 Statement of Law Copyright of this document belongs to Daqin New Energy Tech (Taizhou) Co., Ltd. No part of this documentation maybe excerpted, reproduced, translated, annotated or duplicated in any form or by any means without the prior written authorization of Daqin New Energy Tech (Taizhou) Co., Ltd.

  • Page 4: Safety Precautions

    ⚫ The surface of the PowerDepot H5 cabinet is affixed with a torn invalid label. Therefore, before opening the cover to change the DIP switch mode, you need to contact and inform us the product ID. We will record this battery ID and authorize the opening operation to be performed.

  • Page 5: Preface

    Preface Manual Description PowerDepot H5 Lithium Iron Phosphate Battery is external battery module which can store the electricity for home use. When you apply the grid or photovoltaic system as your powers supply, the product can collect electricity to charges the battery. When grid or photovoltaic system is power off , the product can supply electricity itself for your home loads.

  • Page 6: Introduction

    1 Introduction 1.1 Brief Introduction PowerDepot H5 series is equipped with lithium iron phosphate battery for family use . We base on customer needs and market requirement to develop cutting-edge battery storage technology and offer this high quality product to supply stable electricity for all kind of user’...

  • Page 7: Product Identity Definition

    PowerDepot H5 series User Manual 1.3 Product identity definition FIG1-1 Battery Energy Storage System nameplate Battery voltage is higher than safe voltage, direct contact may cause electric shock hazard. Be careful with your actions and be aware of the dangers.

  • Page 8: Product Specification

    PowerDepot H5 series User Manual 2 Product Specification 2.1 Size and Weight Table 2-1 PowerDepot H5 series device model Specification Nominal Nominal Dimension Weight IP Level Model Voltage Capacity (mm) (kg) PowerDepot H5 100Ah 574*228*600mm 65kg IP65 -5.0 PowerDepot H5...
  • Page 9 PowerDepot H5 series User Manual Table 2-3 Interface Definition Item Name Definition The battery DC output positive pole, which is connected to the Positive socket positive pole of the inverter through the cable When the system is used independently: The CAN/RS485 socket is connected to the inverter CAN/RS485 interface through the communication cable.

  • Page 10: Battery Management System(Bms)

    72 hours. Ground Shell ground connection connection point DC circuit breaker Circuit protection Table 2-4 LED status indicators (Take PowerDepot H5-5.0 as an example) Protect/Alar Directions State Led1 Led2 m/Normal Shut down All off ●...

  • Page 11: Current Protection

    PowerDepot H5 series User Manual 2.4.2 Current Protection Over Current Protection in Charging： When the charge current of each module＞45A, current limit protection mode is activated, current will be limited to 5A，protection is removed after rated time delaying 10S. Circulate like this until the current is lower than 45A.

  • Page 12: Installation And Configuration

    PowerDepot H5 series User Manual 3 Installation and Configuration 3.1 Preparations for installation Safety Requirement The product can only be installed by personnel who have been trained in the power-supply system and have sufficient knowledge of the electrical power system.

  • Page 13: Tools And Data

    PowerDepot H5 series User Manual 3.1.2 Tools and data Tools and meters that may be used for installation are shown in table 3-1. Table 3-1 Tool instrument Name Multimeter Screwdriver（Slotted、Phillips） Torque wrench Clamp current meter Diagonal pliers Insulation tape Pointed nose pliers...
  • Page 14 PowerDepot H5 series User Manual ⚫ In the process of unpacking, handle with care and protect the surface coating of the object. ⚫ Open the package, the professional installation personnel should read the technical documents, verify the list, according to the configuration table and packing list, ensure objects are complete and intact.

  • Page 15: Engineering Coordination

    PowerDepot H5 series User Manual 3.1.5 Engineering coordination Attention should be paid to the following items before construction: ⚫ Power cable specification. ⚫ The power cable specification shall meet the requirements of maximum discharge current for each product. ⚫ Mounting space and bearing capacity.

  • Page 16: Floor Installation

    PowerDepot H5 series User Manual Table 3-2 Installation steps 1. Ensure that the battery is in a shutdown state Step1 System outage (Disconnect the battery power cable and press the Reset button to turn it off) 1. bracket check Mechanical...

  • Page 17: Mounted On The Wall

    PowerDepot H5 series User Manual Fixing the shell of the M6 expansion 4． bolt into the hole on the wall. Use the M6 bolt to fix the Support 5． bracket on the wall and control the torque force at 6NM.
  • Page 18 PowerDepot H5 series User Manual Installation procedure： Use the positioning cardboard 1． (provided in accessory package) and mark the screw hole positions on the wall, as shown eight holes in the picture on the left. The cardboard must be perpendicular 2．...

  • Page 19: Electrical Installation

    PowerDepot H5 series User Manual Carry the battery box to the installed Battery bottom bracket. Use M6 bolts to connect the Support bracket&bottom bracket with the box and control the torque force 6NM. 3.2.3 Electrical installation Use multimeter to measure the device before power cable connection procedure. Check the cable continuity, confirm positive and negative and mark the cable labels.
  • Page 20 Module No.1 to the correct mode. Before opening the front panel to operate, you must inform us the ID of the PowerDepot H5. We will record the battery ID and give device opening operation authorization. Except changing the DIP switch mode, no other operations can be done .
  • Page 21 PowerDepot H5 series User Manual Table 3-3 Pin Definition Foot position Color Definition PIN1 Orange/white 485A PIN2 Orange XGND PIN3 Green/white 485B PIN4 Blue CANH PIN5 Blue/white CANL PIN6 Green Reserved PIN7 Brown/white PIN8 Brown Reserved Battery+ Battery- INVERTER PowerDepot...
  • Page 22 When the system used in parallel: ② When the system is used in parallel, it supports up to 3 PowerDepot H5 in parallel. According to the number of parallel system (Take three PowerDepot H5 in parallel as an example), the system needs to use: Power cable × 3pair, Battery-Inverter communication cable ×...

  • Page 23: Battery Module Dip Switch Definition And Description

    DIP switch position (host communication protocol and baud rate selection) spare Host or slave Baud rate selection OFF:slave OFF：CAN: 500K,485: 9600 ON:host ON：CAN: 250K,485: 115200 DIP switch description: For PowerDepot H5 series system, the No. 1 module near the front panel side is the host, another one is slave.
  • Page 24 PowerDepot H5 series User Manual Slave module No.1 Module Front panel Host module When the battery is connected in parallel, the host can communicate with the slave through the CAN interface. The host summarizes the information of the entire battery system and communicates with the inverter through CAN or 485.
  • Page 25 IMEON、Infinisolar、Sungrow、SMA、RENAC、DELIOS、SAJ(CAN Comm) ， Growatt HVM-ES/WPV(CAN port) ,before connecting you need confirm that the DIP switch mode of the host module in PowerDepot H5 is 0010("# 3" to "ON" ,generally factory default is this 0010 mode). (3) If the battery communicates with the Axpert-king,Axpert-VMIII,Growatt SPH/SPA(CAN comm)、GMDE、Saj(485 comm),change the host module DIP switch to 0100(“#2”to“ON”)
  • Page 26 2. Generally factory default DIP switch status of the host module in PowerDepot H5 is Mode 1. When they are used in parallel, all the slave PowerDepot H5 systems need to be opened the cover and change the DIP switch of the host module to Mode 5 (i.e.
  • Page 27 PowerDepot H5 series User Manual a. Remove the four screws on the cover and open the cover. host b. Find the red DIP switch on the host module and confirm the status of the DIP switch. host c. Set the DIP switch to the original state (Mode5: i.e. ADD: 0000) d.
  • Page 28 If the equation holds after calculation, it means communication between PowerDepot H5 and PowerDepot H5 is normal. 2. If the PowerDepot H5 light board shows three different colors flash alternately, it means the communication between PowerDepot H5 is fault. Table 3-3 Battery& Inverter power matching table...

  • Page 29: Battery Parameter Settings On The Inverter

    3.2.6 Register on the website after installation After the battery system installation is completed and the running is normal, you need to log in to the DYNESS official website to register the product installation and use information to make the product warranty effective. Please follow the instructions on the website to register.

  • Page 30: Use, Maintenance And Troubleshooting

    PowerDepot H5 series User Manual 4 Use, maintenance and troubleshooting 4.1 Battery system usage and operation instructions After completing the electrical installation, follow steps below to start the battery system. Check whether the breaker is in OFF state. Press the battery power button, the power button LED light is on, and 2 LED indicator lights will be on and show the green color after self-check.

  • Page 31: Alarm Description And Processing

    PowerDepot H5 series User Manual Check whether the indicator light for the inverter and the battery connection (the communication indicator and the battery access status indicator) is in normal condition. If normal, the connection between the battery and the inverter is completed.
  • Page 32 PowerDepot H5 series User Manual Table 4-2 minor alarm Alert category Alarm indication Countermeasure System working status: Stop discharging, and charge 0%＜SOC≤10% yellow light is always on the battery system in time. 4.3 Analysis and treatment of common faults Item...
  • Page 33 PowerDepot H5 series User Manual Daqin New Energy Tech (Taizhou) Co., Ltd Address: Building 13, Kunshan Jiangyan Industrial Park, Chenzhuang West Road, Jiangyan District, Taizhou City, Jiangsu Province, China, 225500. Email: sales@dyness.net Website: http://www.dyness-tech.com.cn...
