Larson Electronics GL-30675-F Instruction Manual

Golight Stryker Wireless Remote Control Flood and
Spot Light Combo - Handheld and Dash Mount Remote
The GL-30675-F LED Golight Stryker Combination Spotlight/Floodlight from Larson
Electronics produces a 2,520 lumen light beam capable of reaching over 900 feet in
distance in spot and 150 feet in distance by 125 feet in width. This 36 watt LED Golight
offers wireless remote pan and tilt control, a portable handheld remote control, a dash
mounted remote control and a housing finished in a durable white finish. This Golight is
weatherproof with a weatherproof remote control and operates with 12 Volt DC.

MOUNTING INSTRUCTIONS

Light Unit/Magnetic Mount
The light is magnetically mounted. The magnet is water tight and has a 100 pound grip base and is
tested to 60 mph.
Note: Once power is applied to the system the light will pan and tilt prior to illumination. Each
spotlight needs to be wired on a single dedicated circuit and the power fused at 5 amps. With the
power connected, your light is ready for operation.

POWER SUPPLY

This light operates with 12 volts DC and draws 3 amps, making it ideal for vehicles, boats, ATVs, and similar
sources of 12 volt direct current. It is equipped with a 16 foot, outdoor rated cord with a cigarette plug. Weather
tight connector enables operators to disconnect cord at 12 inches from the light for storage or vehicle
portability.

REMOTE OPERATION

Remote control functions include on/off, and 4 buttons which control up, down, left and right
movement. The light will continue movement as long as the buttons are pressed. Releasing the
buttons stops movement and holds the Golight in position. A fast and slow mode button (turtle/hare)
controls the speed of the motor while the pan and tilt function buttons are depressed. Holding the
button for 12 seconds in fast mode results in a full 370 degree rotation, and 8 seconds for full tilt. Slow
mode is used for pinpoint accuracy at distance and is approximately 35 seconds for full rotation and 20
seconds for one full range of tilt.

BATTERY

Both remotes includes have an internal 12 volt battery rated at 1 year of operation and a single red
LED to indicate remote control activity.

PROGRAMMABLE REMOTE INSTRUCTIONS

Remote Control Programmable with More than 60,000 Possible Channels. Remotes Can be
Programmed to Control One Golight or Several.
