16. Firmly tighten the four 3/8" x 2 3/8" Screws
(3) and the two 3/8" x 1 1/4" Screws (1).
Next, tighten the two 3/8" x 1 3/4" Screws (4);
make sure that the Wheels (93) turn freely.
Next, set the Left Inner Base Cover (99) onto the
lower end of the Left Upright (91). Slide the Left
Base Cover (97) downward and press it onto the
Left Inner Base Cover.
Then, set the Right Inner Base Cover (100) onto
the lower end of the Right Upright (92). Slide the
Right Base Cover (98) downward and press it
onto the Right Inner Base Cover.
Then, lower the Frame (64) (see HOW TO
LOWER THE TREADMILL FOR USE on
page 28).
17. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the fl oor or carpet, place a mat under the treadmill. To
avoid damage to the console, keep the treadmill out of direct sunlight. Keep the included hex keys in a secure
place; one of the hex keys is used to adjust the walking belt (see pages 30 and 31). Note: Extra parts may be
included.
16
97
3
91
1
15
64
1
3
99
4
100
4
93
92
98
93
