▶ Instructions must be available to each user. ▶ The device may not be used in outdoor locations. ▶ The liability and warranty for Type 6144 are void if the operating ▶ Always observe the conditions for operations and use and the instructions are not followed.
BASIC SAFETY INSTRUCTIONS ▶ Devices without a separate Ex rating plate may not be used in a potentially explosive area. These safety instructions do not make allowance for any contin- ▶ Do not make any internal or external changes on the device and do gencies and events which may arise during installation, operation and not subject it to mechanical stress.
STRUCTURE AND FUNCTION The Flipper Valve Type 6144 is a 3/2-way solenoid valve that can be operated either electrically (monostable or bistable) or mechanically via manual actuation. TECHNICAL DATA 6.1 Operating conditions WARNING! Danger of injury due to function failure.
Ambient temperature -10 to +55 °C 6.3 Type plate Fluid temperature -10 to +55 °C Example: WWC Fluids Compressed air: oiled, oil-free or dry; neutral liquids and gases (5 µm filtering);Technical vacuum. Protection category IP40 with rectangular connector Protection class 3 acc.
6.4 Pneumatic data 6.5 Labelling of the electrical and fluid connections Circuit functions 3/2-way valve, direct acting, outlet 2 depres- surized when deenergized Electrical connection 3/2-way valve, direct acting, outlet 2 pres- surized when deenergized Fluidische Anschlüsse Closed with no current (NC), com- Fluid connection 1 NC pressed-air connection...
6.6 Electrical data ASSEMBLY Correct polarity is essential for the 7.1 Safety instructions device to function. WARNING! See chapter „6.5 Labelling of the electrical and fluid connections“ Assembly work may result in hazardous situations. Operating voltage as per type plate ± 10 % ▶...
Page 9
7.2 Fluid installations Assembly of Type 6144 with Bürkert flange: (see Figure 1: Assembly drawing for Bürkert flange) WARNING! WARNING! Danger of injury from high pressure. Danger of escaping fluids! ▶ Before detaching lines and valves, cut off pressure and vent.
Page 10
Fastening Valve with fastening elements Valve with fastening screws elements Sealing mat Hole pattern: Fig. 2: Assembly drawing for lateral flange M 1,6 max. Ø2 Sealing mat Connection plate 21,5 Fig. 1: Assembly drawing for Bürkert flange english...
Page 11
Pin assignment ( FS 09) Pin assignment ( FS 11) Valve with fastening elements Hole pattern: Sealing mat M 1,6 M 1,6 max. ø1,6 max. ø1,6 10,4 10,4 Pin assignment ( FS 18) Pin assignmen ( FS 17) max. Ø2 M 1,6 21,5 M 1,6...
7.2.1. Manual actuation 7.2.2. Description of variants • The valve can be actuated manually via a hand lever. • The location and function of the manual override and the position of the fluid connections vary depending on the design (see the fol- NOTE! lowing table).
Electrical connection: MAINTENANCE / MALFUNCTIONS 7.3.1. Observe voltage and type of current in accordance with type plate. NOTE! Connection with direct current: Damage caused by electrostatic charge. Standard version An electrostatic discharge may damage the device. with rectangular plug • Clean the device surface of the flipper valve by gently wiping it with a damp cloth.
PACKAGING, TRANSPORT, STORAGE NOTE! Transport damages. Inadequately protected equipment may be damaged during transport. • During transportation protect the device against wet and dirt in shock- resistant packaging. • Avoid exceeding or dropping below the allowable storage temperature. Incorrect storage may damage the device. •...
