ORIGINAL INSTRUCTIONS
OPERATOR'S MANUAL
40TL
Loader
Part number 90441890
3
edition English
rd
December 2020
Replaces part number 48070328

Advertisement

Table of Contents
loading

Related Manuals for New Holland 140TL

Summary of Contents for New Holland 140TL

  • Page 1 ORIGINAL INSTRUCTIONS OPERATOR’S MANUAL 40TL Loader Part number 90441890 edition English December 2020 Replaces part number 48070328...

  • Page 2: Table Of Contents

    Contents 1 GENERAL INFORMATION Note to the owner................1-1 Manual scope and required training level .
  • Page 3 Recommended Lubricants ............. 5-5 MAINTENANCE CHART Maintenance planning .

  • Page 5: General Information

    Your NEW HOLLAND dealer will instruct you in the general operation of your new equipment. (Refer to the 'Delivery Report' at the back of this manual.) Your dealer's staff of factory-trained service technicians will be glad to answer any questions that may arise regarding the operation of your machine.
  • Page 6 1 - GENERAL INFORMATION Intended use The loader was designed to mount on NEW HOLLAND approved tractors. The loader is designed to load and move materials with a variety of buckets and approved NEW HOLLAND attachments. DO NOT use this machine for any purpose or in any man-...

  • Page 7: Manual Scope And Required Training Level

    NEW HOLLAND during normal operation, routine service, and maintenance. Periodic service consists of activities that are necessary to maintain the expected life of the NEW HOLLAND ma- This manual does not contain all the information that re- chine. These activities have defined intervals.
  • Page 8 1 - GENERAL INFORMATION demonstrate the ability to operate and service the NEW HOLLAND machine in a correct and safe manner.

  • Page 9: Ecology And The Environment

    Your NEW HOLLAND dealer or air-condi- fect of these substances on man and nature and how to tioning specialist has a special extractor for this pur- safely store, use, and dispose of these substances.

  • Page 10: International Symbols

    1 - GENERAL INFORMATION International symbols As a guide to the operation of the machine, various universal symbols have been utilized on the instruments, controls, switches, and fuse box. The symbols are shown below with an indication of their meaning. Thermostart Position Radio...

  • Page 11: Torque - Minimum Tightening Torques For Normal Assembly

    1 - GENERAL INFORMATION Torque - Minimum Tightening Torques for Normal Assembly METRIC NON-FLANGED HARDWARE NOM. LOCKNUT LOCKNUT SIZE CL.8 CL.10 CLASS 8.8 BOLT and CLASS 10.9 BOLT and W/CL8.8 W/CL10.9 CLASS 8 NUT CLASS 10 NUT BOLT BOLT PLATED PLATED UNPLATED UNPLATED...
  • Page 12 1 - GENERAL INFORMATION Metric Hex nuts and locknuts, classes 05 and up 20083681 1. Manufacturer's Identification 3. Clock Marking of Property Class and Manufacturer's Identification (Optional), i.e. marks 60° apart indicate 2. Property Class Class 10 properties, and marks 120° apart indicate Class 8.
  • Page 13 1 - GENERAL INFORMATION IDENTIFICATION Inch Bolts and free-spinning nuts 20083682 Grade Marking Examples SAE Grade Identification Grade 2 - No Marks Grade 2 Nut - No Marks Grade 5 - Three Marks Grade 5 Nut - Marks 120° Apart Grade 8 - Five Marks Grade 8 Nut - Marks 60°...

  • Page 14: Torque - Standard Torque Data For Hydraulics

    1 - GENERAL INFORMATION Torque - Standard torque data for hydraulics INSTALLATION OF ADJUSTABLE FITTINGS IN STRAIGHT THREAD O RING BOSSES 1. Lubricate the O-ring by coating it with a light oil or petroleum. Install the O-ring in the groove adjacent to the metal backup washer which is assembled at the extreme end of the groove (4).
  • Page 15 1 - GENERAL INFORMATION PIPE THREAD FITTING TORQUE PIPE THREAD FITTING Thread Size Torque (Maximum) Before installing and tightening pipe fittings, clean the 1/8-27 13 N·m (10 lb ft) threads with a clean solvent or Loctite cleaner and ap- 1/4-18 16 N·m (12 lb ft) ply sealant for all fittings including stainless steel or for 3/8-18...

  • Page 16: Product Identification

    1 - GENERAL INFORMATION Product identification PRODUCT IDENTIFICATION PLATE A product identification plate is located on the inside of the left-hand loader frame. NHIL15CT00501AA The identification numbers on this plate are important in the event that your loader should require future service. 36086829 1-12...

  • Page 17: Machine Orientation

    1 - GENERAL INFORMATION Machine orientation NOTE: On this equipment, left–hand and right-hand are determined by standing behind the unit, looking in the di- rection of travel. NHIL15CT00502AA NHIL15CT00503AA Left-hand view Right-hand view NHIL15CT00505AA NHIL15CT00504AA Rear view Front view 1-13...

  • Page 18: Product Overview

    1 - GENERAL INFORMATION Product overview The 140TL loader is designed to be compatible with the Workmaster™ Hydro-Static Transmission (HST) or me- chanical transmission compact tractors. NHIL16CT02175FA The loader is a quick attach unit, and no tools are required to mount or dismount the loader from the tractor. The loader also has its own park stand (1).

  • Page 19: Safety Information

    2 - SAFETY INFORMATION 2 - SAFETY INFORMATION###_2_### Safety rules and signal word definitions Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual and on machine safety signs, you will find the signal words DANGER, WARNING, and CAU- TION followed by special instructions.

  • Page 20: Safety Rules

    2 - SAFETY INFORMATION Safety rules General safety rules Use caution when you operate the machine on slopes. Keep clear of moving parts. Loose clothing, jewelry, Raised equipment, full tanks and other loads will change watches, long hair, and other loose or hanging items can the center of gravity of the machine.
  • Page 21 2 - SAFETY INFORMATION Before you leave the machine: 1. Bring the engine to low idle speed. 1. Park the machine on a firm, level surface. 2. Disengage all drive systems. 2. Put all controls in neutral or park lock position. WARNING 3.
  • Page 22 2 - SAFETY INFORMATION Make sure that the SMV emblem is visible. Be aware of overhead structures or power lines and make sure that the machine and/or attachments can pass safely Make sure that the brake pedal latch is engaged. You under.
  • Page 23 2 - SAFETY INFORMATION Personal Protective Equipment (PPE) Wear Personal Protective Equipment (PPE) such as hard hat, eye protection, heavy gloves, hearing protection, pro- tective clothing, etc. Do Not Operate tag Before you start servicing the machine, attach a ‘Do Not Operate’...
  • Page 24 2 - SAFETY INFORMATION Mounting and dismounting Mount and dismount the machine only at designated lo- Maintain a three-point contact with steps, ladders, and cations that have handholds, steps, and/or or ladders. handholds. Do not jump off of the machine. Never mount or dismount from a moving machine.

  • Page 25: Precautionary Statements

    2 - SAFETY INFORMATION Precautionary Statements A careful operator is the best operator. Most accidents can be avoided by observing certain precautions. To help prevent accidents, read the following precautions before operating this equipment. Equipment should be operated only by those who are responsible and instructed to do so. Carefully review the procedures given in this manual with all operators.
  • Page 26 12. Handling large heavy objects can be extremely or alter, the loader or any of its components or any dangerous due to: loader function without first consulting a New Holland • danger of rolling the tractor over. dealer. If you have any questions regarding loader modifications, contact New Holland .

  • Page 27: Safety Signs

    3. Do not use solvent, gasoline or other harsh chemicals to clean Safety signs. Solvents, gasoline, and other harsh chemicals may damage or remove Safety signs. 2. Replace all Safety signs that are damaged, missing, painted over or illegible. See your NEW HOLLAND dealer for replacement Safety signs.
  • Page 28 2 - SAFETY INFORMATION DANGER Use ROPS and seat belt at all times. Add recommended rear ballast. Operate tractor at low speeds. Do not handle large objects unless tractor is equipped with proper attachments. Operate loader only with approved hydraulic valves. Handle raised loads carefully.
  • Page 29 2 - SAFETY INFORMATION WARNING LOADER SAFETY Operate loader only from operator's seat. When parking or servicing unit, lower the bucket to the ground, stop engine, and set the parking brake. REMOVING OR INSTALLING LOADER. Park detached loader on hard level ground. Have an attachment mounted to loader when removed from tractor.
  • Page 30 2 - SAFETY INFORMATION Danger Do not walk or work under raised loader. Lower loader to ground when parked. Failure to comply will result in death or serious injury. Quantity 2 English 86979961 French 87045259 86979961 (4) Left-hand side loader boom. NHIL15CT00499AA (4) Right-hand side loader boom.
  • Page 31 2 - SAFETY INFORMATION WARNING To avoid injury or death from falling attachments, make sure both lock pins are fully engaged and protruding through frame. Failure to comply could result in death or serious injury. Quantity 2 English 84402769 French 47510444 84402769 (4) Left-hand side loader boom.

  • Page 32: Safety Features

    2 - SAFETY INFORMATION Safety features See 1-14 for safety feature description of the park stand. 2-14...

  • Page 33: Operating Instructions

    3 - OPERATING INSTRUCTIONS 3 - OPERATING INSTRUCTIONS###_4_### COMMISSIONING THE UNIT Machine preparation Machine Preparation WARNING Improper operation or service of this machine can result in an accident. Read and understand the SAFETY INFORMATION Section before you perform any maintenance, ser- vice, or repairs.

  • Page 34: Installing The Loader

    3 - OPERATING INSTRUCTIONS Installing the loader WARNING Crushing hazard! Never stand between the front of the tractor and the loader cross tubes. Failure to comply could result in death or serious injury. W1075A Preparing to install the loader 1. Pull the hydraulic hoses (1), to the outside of the loader frame (2), so as not to damage them during the instal- lation of the loader.
  • Page 35 3 - OPERATING INSTRUCTIONS Installation of the loader 1. Start the tractor engine, release the brakes, and slowly drive the tractor forward until the tower saddle pins (2), are just forward and above the mount bracket saddles (1). NHIL16CT02172AA 2. Gradually activate the bucket control lever to extend the bucket cylinders which will direct the tower saddle pin (1) down into the mount bracket saddle (2).
  • Page 36 3 - OPERATING INSTRUCTIONS 5. Install the pins (1) from the outside side of loader frame (2). 6. Secure the pins with the safety pins (3). NOTICE: Repeat this step for the opposite side. NHIL16CT02165AA Stowing the park stand WARNING Avoid injury! To install or remove the park stand, raise the loader and then set the loader down on its cutting edge (the bottom surface of the bucket should be vertical).This safely supports the boom while the operator...
  • Page 37 3 - OPERATING INSTRUCTIONS 4. Remove the clips (1) and pins (2) from the loader sup- port legs (3) and fold the legs up into the stowed posi- tion. NHIL15CT00497AA NOTE: The right side support leg MUST be folded up prior to the left side, to allow for proper stowage..

  • Page 38: Connecting The Hydraulics At The Tractor

    3 - OPERATING INSTRUCTIONS Connecting the hydraulics at the tractor Hydraulic hose connection WARNING Crushing hazard! Before disconnecting the cylinders or equipment, make sure you adequately support and secure the equipment or implement. Failure to comply could result in death or serious injury. W0243A WARNING Escaping fluid!

  • Page 39: Installing The Quick-Attach Plate

    3 - OPERATING INSTRUCTIONS Installing the quick-attach plate 1. Start the engine of the tractor and release the parking brake. Slowly drive the tractor toward the quick attach plate, positioning the loader boom in the middle of the attachment points. Stop the engine of the tractor and set the parking brake.

  • Page 40: Installing The Quick-Attach Bucket

    3 - OPERATING INSTRUCTIONS Installing the quick-attach bucket 1. Lower the loader with the quick attach plate (1) posi- tioned below the bucket mounting plates (2) and rolled slightly forward. NOTICE: The area surrounding the quick attach coupler latches and the engagement slots on the bucket must be kept free of debris and foreign material to allow for proper operation of the quick attach locking mechanism.
  • Page 41 3 - OPERATING INSTRUCTIONS 6. Raise the loader and dump the bucket until the cutting edge is resting on the ground. Visually confirm the locking pins (1) on the quick attach plate are engaged and locked in the bucket slots. 7.

  • Page 42: Installing The Bucket Level Indicator

    3 - OPERATING INSTRUCTIONS Installing the bucket level indicator 1. Install the bucket level indicator rod (1) through the hole in the inner right side bucket plate (2). 86060304 2. Install the flat washer (1), and cotter pin (2) onto the rod end.
  • Page 43 3 - OPERATING INSTRUCTIONS 5. Install the U-bolt (1) around the bucket cylinder (2), and through the level indicator bracket (3). Secure the U-bolt, (1) to the level indicator bracket (3) with two lock nuts (4). 86060306 6. When the bucket (1) is in the level position, the bend in the level indicator rod (2) will be located in the indicator bracket (3).

  • Page 44: Parking The Unit

    3 - OPERATING INSTRUCTIONS PARKING THE UNIT Removing the quick-attach bucket WARNING Pressurized hydraulic fluid can penetrate the skin and cause severe injuries. Hydraulic fluid is under extreme pressure. Rest the bucket or attachment on the ground. Shut the engine off, turn the key on, and move the hydraulic control lever through all movements several times to relieve residual pressure in the system.

  • Page 45: Removing The Quick-Attach Plate

    3 - OPERATING INSTRUCTIONS Removing the quick-attach plate 1. Remove the retaining rings (1) on all the mounting pins securing the quick attach plate to the loader. 2. Remove the upper pivot pins (2) inward through the lift links (3) and the quick attach plate (4). 3.

  • Page 46: Removing The Loader

    3 - OPERATING INSTRUCTIONS Removing the loader WARNING Tip-over hazard! Always have an approved bucket mounted to the loader when the loader is removed from the tractor. Pallet fork, bale spear, or similar attachments are too light to safely counterbalance the loader boom arms when the loader is removed from the tractor.
  • Page 47 3 - OPERATING INSTRUCTIONS Deploying the park stand WARNING Avoid injury! To install or remove the park stand, raise the loader and then set the loader down on its cutting edge (the bottom surface of the bucket should be vertical).This safely supports the boom while the operator installs or removes the park stand.
  • Page 48 3 - OPERATING INSTRUCTIONS Removing the loader from the tractor 1. Remove the safety pins (1) and the frame pins (2), from the left-hand and right-hand sides. NHIL16CT02165AA 2. Start the tractor engine and release the brakes. 3. Activate the lift control lever to fully retract lift cylinders. 4.
  • Page 49 3 - OPERATING INSTRUCTIONS 6. Engage the tractor brakes and stop the engine. 7. Activate the control lever to relieve the pressure in both the bucket and lift circuits. 8. Disconnect the quick couplers and install clean dust covers (1) and plugs (2) on all couplers. Position the loader hoses (3) on the loader so they do not contact the ground.
  • Page 50 3 - OPERATING INSTRUCTIONS 3-18...

  • Page 51: Working Operations

    4 - WORKING OPERATIONS 4 - WORKING OPERATIONS###_6_### GENERAL INFORMATION Operating the loader WARNING Avoid injury! Excessive speed is dangerous and may cause spillage and excessive strain on the bucket. Failure to comply could result in death or serious injury. W1306A The loader should be operated with the tractor engine run- ning at 1700 –...
  • Page 52 4 - WORKING OPERATIONS Filling the bucket Approach and enter the pile with a level bucket. NHIL13CT00861AA Ease the single lever control back to lift the bucket and to the left to roll back the bucket. NHIL13CT00862AA...
  • Page 53 4 - WORKING OPERATIONS The lift and rollback of the bucket increases efficiency. (1) Do this. NHIL13CT00863AA This is because a level bucket throughout the lifting cycle resists bucket lift and increases breakaway effort. (2) Not This NHIL13CT00864AA WARNING Roll-over hazard! A full bucket in the raised position alters the center of gravity of the ma- chine.
  • Page 54 4 - WORKING OPERATIONS Carrying the load Position the bucket just below the level of the tractor hood. This provides for maximum stability and visibility, whether the bucket is loaded or empty. NHIL13CT00866AA Carry the bucket as low as possible when operating the loader on a slope.
  • Page 55 4 - WORKING OPERATIONS Operating with float control The bucket will wear faster if hydraulic down pressure is exerted during loader operation. To prevent this from oc- curring, keep the bucket level and put the lift control in the float position during hard surface operation, allowing the bucket to float on the working surface.
  • Page 56 4 - WORKING OPERATIONS If the pile sides are too high and likely to cause cave-in, use the loader to break down the sides until a slot can be cut over the top. NHIL13CT00874AA Another effective method of loading from large dirt piles is to build a ramp approach NHIL13CT00875AA NOTE: Keep the bucket level when approaching a bank...
  • Page 57 4 - WORKING OPERATIONS With the bucket level, start a cut at the notch approxi- mately 51 mm (2 in) deep. Hold the depth by feather- ing the bucket control to adjust the cutting lip up or down. When the front tires enter the notch, adjust the lift cylinder to maintain proper depth.
  • Page 58 4 - WORKING OPERATIONS Backfilling Approach the pile with a flat bucket. Poor methods move no more dirt and make it more difficult to hold a level grade. (1) Do this NHIL13CT00882AA When bulldozing, do not use the bucket in the dumped position.
  • Page 59 4 - WORKING OPERATIONS Leave any dirt which drifts over the side of the bucket for final cleanup. (2) Ditch NHIL13CT00886AA Pile dirt on the high side for easier backfilling on a slope. NHIL13CT00887AA...

  • Page 60: Front Remote Control Valve

    4 - WORKING OPERATIONS Front remote control valve Front Remote Control Valve Workmaster™ 35 or 40 The front remote control valve (1) is mounted to the front of the right-hand fender. This valve is used mainly for front end loader operation, but may also be used to operate other front mounted implements.

  • Page 61: Front Remote Control Valve - Lock Out

    4 - WORKING OPERATIONS Front remote control valve - lock out Front Remote Control Valve Workmaster™ 35 or 40 The two spool valve is equipped with a valve lock feature. The valve lock, mechanically locks the boom and bucket spool linkages in the neutral position. To operate lock, pull the lever (1) outward to release valve lock.
  • Page 62 4 - WORKING OPERATIONS 4-12...

  • Page 63: Maintenance

    NOTICE: Always use genuine NEW HOLLAND replacement parts, oils and filters to ensure proper operation, filtration of engine and hydraulic systems. See your NEW HOLLAND dealer for additional oil quantities.

  • Page 64: Daily Inspection

    5 - MAINTENANCE Daily inspection WARNING Crushing hazard! Before attempting any maintenance on the loader or tractor, always make sure the loader is in the down position and the bucket or attachment is resting on the ground. Failure to comply could result in death or serious injury. W0119A Optimum machine performance and long life can only be and replacement of worn or damaged parts.
  • Page 65 5 - MAINTENANCE WARNING Pressurized hydraulic fluid can penetrate the skin and cause severe injuries. Tighten all of the connections before starting the engine. If hydraulic fluid has penetrated the skin, seek medical assistance immediately. Failure to comply could result in death or serious injury. W0117A WARNING Crushing hazard!

  • Page 66: Hydraulics

    5 - MAINTENANCE Hydraulics NHIL15CT00500FA Ref. Description Qty. Bucket cylinder rod end hose Bucket cylinder base end hose Lift cylinder rod end hose Lift cylinder base end hose Hydraulic tube lift cylinder rod end Hydraulic tube lift cylinder base end Hydraulic tube bucket cylinder base end Hydraulic tube bucket cylinder rod end Hydraulic hose 3/8"...

  • Page 67: Recommended Lubricants

    5 - MAINTENANCE Recommended Lubricants Lubricant Type and Description Part Number Container Size Transmission/Hydraulic Oil 9624655DS 0.946 l (1 US qt) YDRAULIC RANSMISSION REMIUM 9624656DS 3.785 l (1 US gal) 9624450 9.46 l (2.5 US gal) 9624451 18.93 l (5 US gal) 86523625DS 3.785 l (1 US gal) ULTI...

  • Page 68: Maintenance Chart

    5 - MAINTENANCE MAINTENANCE CHART Maintenance planning Lubricate Check Maintenance action Page no. Every 8 hours or daily Front loader and bucket - Lubricate DAILY x 5-6 Tractor hydraulic oil reservoir - Check After the first 10 hours of operation x 5-6 Hardware - Check 50 hours...

  • Page 69: Hours

    5 - MAINTENANCE 50 hours Hardware - Check Check all loader mount hardware after 10 hours of op- eration and every 50 hours of operation thereafter.
  • Page 70 5 - MAINTENANCE...

  • Page 71: Troubleshooting

    6 - TROUBLESHOOTING TROUBLESHOOTING###_8_### SYMPTOM(S) Front loader and bucket - Troubleshooting Problem Possible Cause Correction Loader is slow or will not Hydraulic oil too heavy. Change to proper oil ( or for cold weather lift and/or dump. operation). Tractor hydraulic filter plugged. Replace filter.
  • Page 72 6 - TROUBLESHOOTING...

  • Page 73: Specifications

    7 - SPECIFICATIONS SPECIFICATIONS###_9_### Loader specifications 140TL Tractor Model Workmaster™ Hydro-Static Transmission (HST) or mechanical transmission Bucket 68 in. HD Mat'l Tires 25X8.50-14 6PR (R4) front 43x16.00-20 4PR (R4) rear Rated flow 31 L/min (8 US gpm) Rated pressure 16671 kPa (2418 psi)
  • Page 74 7 - SPECIFICATIONS 20022390B (A) Maximum Lift Height to Pivot Pin (F) Reach with Bucket on Ground (B) Maximum Lift Height Under Level Bucket (G) Maximum Rollback Angle (C) Clearance with Bucket Dumped @ 45° (H) Digging Depth (D) Reach at Maximum Lift Height with Bucket (WB) Wheelbase Dumped @ 45°...

  • Page 75: Weight Limitations

    7 - SPECIFICATIONS Weight Limitations Rear Counter Weight Bracket (Optional) Weight bracket (1) fits any 3 point hitch. Maximum of seven suitcase weights. 27 kg (60 lb) each - 191.0 kg (420 lb) total (2) 27 kg (60 lb) (5) 45 kg (100 lb) - 282 kg (620 lb) total 10032795 Ballasting Box A Category-1, 3-point hitch, 180 kg (400 lb) capacity bal-...

  • Page 76: Liquid Ballast

    Never exceed the total recommended weight for the trac- Failure to comply could result in death or se- tor. Because special equipment is required to fill the tires, rious injury. consult your New Holland Dealer. W0291A Workmaster™Hydro-Static Transmission (HST) or mechanical transmission Ballast Type...
  • Page 77 7 - SPECIFICATIONS 140TL on a Workmaster™Hydro-Static Transmission (HST) or mechanical transmission (25% on Rear Axle) Option Bucket Wheel Hitch Total Front Axle Rear Axle Front Axle, Rear Axle, Load @ Ballast Ballast Weight Load Load Hood [kg (lbs)] [kg (lbs)]...

  • Page 78: Tire Pressure

    7 - SPECIFICATIONS Tire pressure NOTICE: Tire pressure must be considered when adding weights, implements, or attachments to the tractor or dam- age to the tractor may occur. NOTICE: Do not install loader onto tractor equipped with galaxy turf tires. The turf tires cannot handle the added weight of loader, and damage may occur to the tractor.

  • Page 79: Accessories

    8 - ACCESSORIES ACCESSORIES###_10_### Attachments "Quick Attach" Only 19990486 Attachment Description Size Weight Pallet Forks [ 1067 mm (42 in) or 1067 mm (42 in) or 1219 mm (48 in) Frame - 104 kg (230 lb) 1219 mm (48 in)] 1067 mm (42 in) - 73 kg (160 lb) Frame and Forks sold separately 1219 mm (48 in) - 100 kg (220 lb)
  • Page 80 8 - ACCESSORIES...

  • Page 81: Forms And Declarations

    9 - FORMS AND DECLARATIONS 9 - FORMS AND DECLARATIONS###_11_### Delivery Report- Owner Copy - Owner Copy Delivery Date Owner's Name Address Dealer's Name Address Unit: Model Product Identification Number Attachment: Model Product Identification Number Model Product Identification Number Model Product Identification Number Using the operator's manual as a guide, instruction was given as indicated by the...

  • Page 82: Delivery Report - Dealer Copy - Dealer Copy

    9 - FORMS AND DECLARATIONS Delivery report - Dealer copy - Dealer Copy Delivery Date Owner's Name Address Dealer's Name Address Unit: Model Product Identification Number Attachment: Model Product Identification Number Model Product Identification Number Model Product Identification Number Using the operator's manual as a guide, instruction was given as indicated by the check marks.
