- Page 1 FSDLC-220-047 INSTRUCTION MANUAL PLUG-IN TRANSDUCER FINE SERIES ALARM SETTER FSDLC...
- Page 2 Aluminum electrolytic capacitors are used in products. Please energize the power supply within one year after purchase. Countermeasures against troubles If trouble occurs within the warranty period, DAIICHI ELECTRONICS will repairs this product. Disposal Please dispose this product as industrial waste (non-combustible).
-
Page 3: Table Of Contents
FSDLC-220-047 Contents 1. Outline on the product ････････････････････････････････････････････････ 3 1.1 Features of product ････････････････････････････････････････････････ 3 2. Installation 2.1 Outline dimensions ･････････････････････････････････････････････････ 3 2.2 Connections ････････････････････････････････････････････････････････ 5 2.3 About of auxiliary supply ･･････････････････････････････････････････ 6 2.4 Cautions on installation ･･･････････････････････････････････････････ 6 2.5 LCD viewing angle ･･････････････････････････････････････････････････ 6 3. -
Page 4: Outline On The Product
FSDLC-220-047 1. Outline on the product This product is a small plug-in structure alarm setter. This product takes a DC voltage or DC current signal as input, compares it with the preset operating point, and outputs the excess or deficiency as a contact signal. The full scale of the input can be arbitrarily set on the actual scale according to the process amount, and each set value (operating value, contact delay, etc.) can also be set freely. - Page 5 FSDLC-220-047 (2) Precision Resistance Unit, Type：UR-2 (option) AWG22 (60mm) 11.2 UR-2 combines an alarm setter of voltage input, and please use it. When open measures are necessary when they change an alarm setter with hot line condition in current input, they connect UR-2 to socket, and please use it by voltage signal.
-
Page 6: Connections
FSDLC-220-047 2.2 Connections ■ Connection diagram 2 contacts 3 contacts 3 contacts Each change over contact (1c) Each normally open contact (1a) Each normally close contact (1b) UNITn UNITn＋1 UNITn UNITn＋1 UNITn UNITn＋1 INPUT INPUT INPUT ＋ － ＋ － ＋... -
Page 7: About Of Auxiliary Supply
FSDLC-220-047 2.3 About of auxiliary supply By applying auxiliary power to the power supply (AUX. SUPPLY) terminal of mounting base, power is supplied to each unit. When mounting base has unit individual power switch. Please insert this product into the mounting base and tighten the screw to fix the main body. An auxiliary power is supplied. -
Page 8: Operation Method
FSDLC-220-047 3. Operation method 3.1 The name and function of each part For 2 contacts For 3 contacts For 4 contacts Display of measured value (real scale) and various settings. The backlight lighted when the key switch is operated. Backlight will be off, if 30 second passes without doing key switch operation. -
Page 9: Measurement Mode
FSDLC-220-047 3.3 Measurement mode After turning on the power supply, measurement mode is entered. The display switches each time the UP key is pressed, and you can check each display (measurement value display, maximum value display, minimum value display). Measurement value display ●... -
Page 10: Display Mode
FSDLC-220-047 3.4 Display mode Setting item is displayed in order and the set value check of all items can be performed. Once it pushes the MODE key, it will change to a display mode. Common item (AL1 to AL4) is changed by the UP key. Each setting item is displayed as the SHIFT key. Measurement value display 5 0 . -
Page 11: Setting Mode
FSDLC-220-047 3.5 Setting mode Change of each set value is possible. If the MODE＋UP key is pushed 3 seconds or more simultaneously, it will change to setting mode. By the same operation as a display mode, a setting item is shifted and it displays. The ENT key is pushed by the item to make a setting change, and setting is changed. - Page 12 FSDLC-220-047 ● Unit display (UNIT) setting. U N I T U N I T U N I T ２ U N I T U N I T After deciding set value change, a setting item symbol is blinking. (UNIT is blinking.) (Middle omission) U N I T U N I T...
-
Page 13: Calibration
FSDLC-220-047 3.6 Calibration Because this product is adjusted beforehand, there is no necessity for calibration. However, if the operating point of an alarm output shifts, please adjust in the next way. (1) After turning on the auxiliary power, perform preliminary energization for 15 minutes. (2) When the input equivalent to the minimum display is applied, in order that it may become the minimum display, set value CBIAS is set up. -
Page 14: Specification And Performance
FSDLC-220-047 5. Specification and performance 5.1 Alarm output specifications Item Specification Output 2 contacts，3 contacts，4 contacts 2 contacts：Each change over contact (1c contact) 3 contacts：Each normally open contact (1a contact) or Contact structure each normally close contact (1b contact) 4 contacts：Each normally open contact (1a contact) [One side two points common] or each normally close contact (1b contact) [One side two points common] Maximum switching load AC120V 1A (COSφ＝1) ，DC30V 1A (Resistance load) - Page 15 FSDLC-220-047 ● Relay contact status 4 contacts 4 contacts Status Each normally open contact (1a contact) Each normally close contact (1b contact) Auxiliary supply UNIT n UNIT n＋1 UNIT n UNIT n＋1 OFF or relay non-excitation Terminal № Terminal № UNIT n UNIT n＋1 UNIT n...
-
Page 16: Relay Action
FSDLC-220-047 5.3 Relay action ■ Contact delay function ５ Relay operation in over-input detection. (Output mode：Excitation, H ( Operation value Setting value setting Dead band Input Relay action Contact delay Contact delay Contact delay setting time setting time setting time ５... -
Page 17: Pre-Alarm Function
FSDLC-220-047 5.4 Pre-alarm function A monitor lamp is blinked among contact delay time until excitation of a relay after operation value detection. Blinking of a monitor lamp will be gradually fast, and when the point of contact delay time passes, a monitor lamp is lights up. If contact delay time setting is made into 0 second, a pre-alarm function constitutes OFF. -
Page 18: Setting Value
FSDLC-220-047 5.5 Setting value Default setting value № Contents Mark Setting range 2 contact 3 contact 4 contact outputs outputs outputs ３ ％ ， m， ℃， m /h， ppm， pH， TPm， ×10kg， Unit display UNIT ％ Ω，kW，No unit Minimum value scaling -9999 to 9999 -9.99 to 99.99 Maximum value scaling... -
Page 19: Performance
FSDLC-220-047 5.6 Performance Item Specification ６ Setting accuracy ( ±0.1％ (％ of input span) ７ ８ Display accuracy ( ±0.1％ (％ of input span) ±1digit Reproducibility of the ±0.1％ (％ of input span) ６ operating point ( ±0.25 seconds of set value (Setting value 0 seconds = 0.5 ± 0.25 seconds) Operating time ９... -
Page 20: Trouble Shooting
FSDLC-220-047 6. Trouble shooting Abnormal phenomenon Cause of estimated Method of settlement Power supply input is not applied Please power supply-input-check and apply. Alarm setter trouble Repair of alarm setter Input is not connected Please confirm connection of input. Not output Abnormal of input Please confirm measurement value. -
Page 21: Composition Of Type And Specification Code
