Maintenance
Gap between the Main Unit and the Toilet Lid
The toilet lid can be removed for thorough cleaning.
Unplug the power plug.
1
Remove the main unit.
2
(Pages 38, 39)
Remove the toilet lid.
3
Slightly tilt the toilet lid to the front.
↓
: Pull the left side outward.
Ⓐ
↓
: Disconnect the hinge from the tab and pull up.
Ⓑ
↓
: Disconnect the right side.
Ⓒ
Wipe with a soft cloth that
4
has been soaked in water
and wrung-out thoroughly.
Reinstall the toilet lid.
5
: Join the pin and the hinge on the right side.
Ⓓ
↓
Slightly tilt the toilet lid to the front.
↓
: While pulling out the left side,
Ⓐ
↓
: Mount by joining the hinge with the tab.
Ⓔ
* Be careful not to pinch your ngers.
6 Mount the main unit.
(Pages 38, 39)
Insert the power plug.
7
The "Power" LED lights up.
8 Open and close the toilet lid
to check the reinstallation.
40
Gap between the Main Unit and the Toilet Lid
(Approximately once a month)
Soft cloth soaked in water Toilet paper, etc.
(May cause damage.)
Removing and Reinstalling
Hold with
both hands
Ⓑ
Ⓐ
Pin
Ⓔ
Tab
Hinge
Hinge

Water Filter Drain Valve

Water Filter Drain Valve
Close the shutoff valve.
1
The water supply stops.
Do not remove the water
shutoff valve is open.
(Otherwise, water may leak out.)
Shutoff
valve
2
Press "Wand
Ⓒ
CLEAN" button.
Open the wand cover. (Release the
pressure from the water supply pipe.)
Unplug the power plug.
3
4 Remove the cover and
Ⓓ
water lter drain valve.
Loosen the water lter drain valve with
a at-head screwdriver and then pull it.
Cover
Flat-head screwdriver
(Approximately once every 6 months)
<If you think the water pressure has weakened>
Clean with a tool such as a
5
toothbrush.
Also, remove any dust from inside the
hole of the water lter drain valve.
CAUTION
Reinstall the water lter
6
drain valve and cover.
lter drain valve while the
Insert the water lter drain valve and use a
at-head screwdriver to tighten it securely.
Insert the power plug.
7
The "Power" LED lights up.
Open the shutoff valve.
8
(Page 19)
Water Filter Drain Valve
