American Dynamics SpeedDome Ultra 8 Quick Reference Manual

SpeedDome

Camera Dome

Configuration Utility
Quick Reference Guide
If you need assistance...
Contact your Sales or Technical Support
Representative.
What is the Dome
Configuration Utility?
The Dome Configuration Utility is used to set
features for your camera dome using a text overlay
menu. This menu is accessed via a keystroke
combination on your camera controller. The utility
provides settings relating to camera functions,
alarms, text display, privacy zones, direction
indicators, and password protection. Some items
supplement similar features that may be available
through your controller or switching system.
To start the utility:
1. Select a dome that you need to configure. Refer to
your controller operating instructions for specific
information.
2. Do one of the following:
−
If the dome is installed in a SensorNet or RS-422
network, press and hold Iris Open, press and
hold a Focus button, and then press Zoom Out
(Zoom Wide).
−
If the dome is installed in a Manchester network,
turn the key switch to Prog, enter 66, and then
press Set Preset (Set Shot).
3. The Dome Configuration Menu appears.
1
DOME CONFIGURATION MENU
PAN/TILT/ZOOM/SYNC OPTS
CAMERA FUNCTIONS
ALARMS/AREAS/HOME/PRESETS/PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
© 2007 Sensormatic Electronics Corp.
SPEEDDOME ULTRA 8 CAMERA DOME CONFIGURATION UTILITY
QUICK REFERENCE GUIDE
Ultra 8
®
Note: If Password Protection is enabled, the Enter
Password screen (Screen 7) appears first.
Choose an option on this screen to change
settings. Table 1 describes the available
commands.
IMPORTANT: Commands may differ depending on
your operating environment. These commands
apply to SensorNet, RS-422, and Manchester.
Table 1. SensorNet, RS-422, and Manchester
commands
If you want to...
Move the Highlight Bar.
Select the highlighted item.
Increase value of selected
setting, or display next choice.
Move cursor to right during
naming.
Decrease value of selected
setting, or display previous
choice.
Move cursor to left during
naming.
Save changes and exit from any
screen.
Pan, Tilt, Zoom and
Synchronization Options
2
PAN/TILT/ZOOM/SYNC OPTS
Screen
RESET TO FACTORY SETTINGS
2
3
4
5
6
•
The default 1st Zoom Stop setting is 52X.
8
•
The default Max Total Zoom setting is 140X.
•
Maximum total zoom settings: Vary depending on the
initial zoom position.
•
The default Line Lock setting is OFF.
•
The default Freeze Frame setting is OFF.
•
For Return to Auto settings, go to Return to Auto
Settings (Screen 2.1).
1 of 11
Use...
Pan/Tilt
Focus
Zoom In
(Zoom Tele)
Zoom Out
(Zoom Wide)
Iris Close,
then Focus
PROPORTIONAL FLIP OFF
1ST ZOOM STOP X
MAX TOTAL ZOOM X 420
LINE LOCK OFF
FREEZE FRAME OFF
RETURN TO AUTO
EXIT
8200-0600-02, REV. B
35
