Summary of Contents for Motomaster Eliminator 011-2102-0
- Page 1 4000 W POWER INVERTER model no. 011-2102-0 IMPORTANT: INSTRUCTION Please read this manual carefully before running this power inverter MANUAL and save it for reference.
- Page 2 headline bars headline bars headline bars model no. KR3000/KR4000 | contact us 1-866-523-5218 tabs tabs tabs continuation tabs continuation tabs continuation tabs notes notes notes Eliminator has been providing Canadians with reliable, affordable automotive ® products that are targeted at the DIY customer. Our extensive line of engine oils and lubricants, antifreeze and coolants, washer fluids, transmission fluids and treatments, winter chemicals, garage and car interior accessories, batteries, chargers and boosters, as well as lifting equipment was developed with our roads...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Information Welcome A Higher Wattage Inverter May Be Required Warnings, Cautions and Notes Warnings: Inverter Output Cautions: Inverter Operating Environment Appliance Cautions Getting Started Front Panel LCD Diagram Hardwire Instructions Rear Panel Cable Gauges Determining the DC Power Requirements Sizing the Battery Bank Understanding Controls and Features Mounting the Inverter... -
Page 4: Safety Information
headline bars headline bars headline bars headline bars headline bars headline bars headline bars model no. 011-2102-0 | contact us 1-888-942-6686 WELCOME WARNINGS, CAUTIONS AND NOTES Please read this manual thoroughly before It is very important that any operator and installer of this inverter read and follow all WARNINGS, installing and operating your new Eliminator ®... -
Page 5: Cautions: Inverter Operating Environment
CAUTIONS: INVERTER OPERATING • Do NOT use this inverter with the above two types of equipment. ENVIRONMENT • The majority of portable appliances do not • Surrounding air temperature should be have this problem. Most portable appliances between -20°C and 40°C (4°F and 104°F) use separate transformers or chargers that –... -
Page 6: Getting Started
headline bars headline bars headline bars model no. 011-2102-0 | contact us 1-888-942-6686 GETTING STARTED When a motorized appliance or a tool turns on, there is an initial surge of power to start. This surge of power is referred to as the "starting load" or "peak load." Once started, the tool or appliance requires less tabs tabs tabs... -
Page 7: Front Panel
FRONT PANEL 011-2102-0 LCD Digital Display (see LCD diagram on Two standard North American AC outlets, next page). each rated at 15 A (1650 W). MENU Button: Pressing the button will Two USB Ports (2.4 A each) : Allows the user to power simultaneously two change the display between OUTPUT 2.4 A-compatible devices such as tablets WATTAGE or INPUT VOLTAGE. -
Page 8: Lcd Diagram
headline bars model no. 011-2102-0 | contact us 1-888-942-6686 LCD DIAGRAM tabs Battery Level. Output Wattage (W) or Input Voltage Display (VDC). Warning Indicator: High voltage b. Low voltage Voltage overload continuation tabs Temperature Shutdown. Remote Instructions The included remote control features an notes LED indicator showing on/off light, push button and 20' (6 m) cable that simply plugs... -
Page 9: Hardwire Instructions
HARDWIRE INSTRUCTIONS 011-2102-0 First make sure unit is completely disconnected from any power source and main power is completely OFF. Begin by unscrewing the front plate which is located under the 2 x AC outlets at the front of the inverter. You will then see the 3 connecting terminals, as illustrated below: NEUTRAL EARTH GROUND... -
Page 10: Rear Panel
headline bars headline bars headline bars model no. 011-2102-0 | contact us 1-888-942-6686 REAR PANEL 011-2102-0 tabs tabs tabs High-Speed Cooling Fans. When Remote Control Receptacle. the temperature inside the inverter Ground Terminal. exceeds a preset limit, the Cooling Fans automatically turn on to cool the inverter. -
Page 11: Cable Gauges
CABLE GAUGES When connecting the inverter to a battery bank use the thickest stranded insulated copper wire available, in the shortest length practicable. Recommended cable gauges are as follows: Model Recommended Gauges Description 011-2100-4 1100 W POWER INVERTER 4 AWG (3’/0.9 m included W/ 110 A inline ANL fuse) 2000 W POWER INVERTER 2 AWG (3’/0.9 m included W/ 200 A inline ANL fuse) 011-2101-2... -
Page 12: Determining The Dc Power Requirements
headline bars model no. 011-2102-0 | contact us 1-888-942-6686 DETERMINING THE DC POWER REQUIREMENTS Powering multiple appliances from the high-power 011-2102-0 power inverter requires a 12 V battery OR a bank of batteries (several batteries). If using a bank of batteries, to calculate the approximate power tabs in amps a 12 V battery bank has to supply, you need to know the current or amps required for powering the continuous AC load. -
Page 13: Understanding Controls And Features
MOUNTING THE INVERTER Your inverter should not be mounted under the hood of a vehicle. Eliminator ® tabs If installing in a vehicle, choose a dry, cool, ventilated area as close to the battery as practical. Before drilling any mounting holes, make sure that there are no wires, fuel lines or tanks directly behind the surface to be drilled. -
Page 14: Operation
headline bars model no. 011-2102-0 | contact us 1-888-942-6686 OPERATION Turn on the inverter. tabs Turn off the inverter. When you have confirmed that the appliance to be operated is turned off, plug an appliance cord into one of the two 120 V AC outlets on the front panel of the inverter. Turn on the inverter. -
Page 15: Operating A Microwave Oven With Your Power Inverter
OPERATING A MICROWAVE OVEN WITH YOUR POWER INVERTER The power rating used with microwave ovens is the "cooking power" which means the power being "delivered" to the food being cooked. The actual operating power rating is listed on the back of the tabs microwave. -
Page 16: Best Use Of Battery Power
headline bars model no. 011-2102-0 | contact us 1-888-942-6686 TROUBLESHOOTING PROBLEM: OUTPUT VOLTAGE BELOW 100 V AC tabs Reason Solution A “True RMS” voltage meter is required to properly Test output voltage with a “True RMS” voltage meter and measure output voltage of a modified wave inverter. the correct voltage will be displayed. -
Page 17: Specifications
SPECIFICATIONS: 011-2102-0 Output Continuous Watts (W) 4000 W + 24 W USB Surge Capacity (Peak Power) 8000 W Rated Input DC (V, A) 13.5 V DC, 350 A Input Voltage Range 10.5 to 16 V DC +/- 0.3 V Rated Frequency (Hz) 60 Hz±1 Rated Output AC (V, A) 120 V +/- 10%, 33.3 A... -
Page 18: Warranty And Returns
This MotoMaster Eliminator product carries a three (3) year warranty against defects in workmanship and materials. At its discretion, MotoMaster Canada agrees to have any defective part(s) repaired or replaced free of charge, within the stated warranty period, when returned by the original purchaser with proof of purchase.
